DocID024647 Rev 1

21/138

RM0352

Clock and reset management unit

137

Clock and reset management unit

5.1

Introduction

The Brain CRMU implements the clock and reset generation for the Brain device. The Brain

CRMU is accessible through an APB interface.

5.2

Clock generation

5.2.1

General description

The system clock can be selected from one of three clocks:

•

80 MHz RC oscillator clock

•

32 kHz RC oscillator clock

Note:

Real frequency is 32.768 kHz. However, it is called 32 kHz throughout the document to

simplify.

•

External single ended input clock

There are four clock dividers in the CRMU which divide the system clock before it is used to

generate the clocks for the peripherals, processor, and memories.

The source of the clock for the processor can be selected from four possible sources:

•

System clock divided by 5 (default)

•

System clock divided by 2, 4, 6, 8, 10, 16, 20, 32

•

System clock divided by 3

•

System clock

By default the system clock divided by 5 is selected as the root point for the AHB and APB

clocks, this is to meet the access time requirements of the Flash memory which is 50 ns. In

the Brain device the processor boots from the information block of the Flash so it is not

possible to boot with the 80 MHz RC oscillator clock. The user can switch to the high speed

clock after the program has been copied into the program RAM.

The system contains a low speed clock which is used for the timers and the watchdog

circuitry. The low speed clock has 2 possible sources:

•

32 KHz RC oscillator clock

•

External single ended input clock
