293 / 482 page  © 2007 Microchip Technology Inc. Preliminary DS39625C-page 291 PIC18F2585/2680/4585/4680 REGISTER 23-16: RXBnSIDL: RECEIVE BUFFER n STANDARD IDENTIFIER REGISTERS, LOW BYTE [0 ≤ n ≤ 1] REGISTER 23-17: RXBnEIDH: RECEIVE BUFFER n EXTENDED IDENTIFIER REGISTERS, HIGH BYTE [0 ≤ n ≤ 1] REGISTER 23-18: RXBnEIDL: RECEIVE BUFFER n EXTENDED IDENTIFIER REGISTERS, LOW BYTE [0 ≤ n ≤ 1] R-x R-x R-x R-x R-x U-0 R-x R-x SID2 SID1 SID0 SRR EXID —EID17 EID16 bit 7 bit 0 bit 7-5 SID2:SID0: Standard Identifier bits (if EXID = 0) Extended Identifier bits EID20:EID18 (if EXID = 1). bit 4 SRR: Substitute Remote Request bit This bit is always ‘0’ when EXID = 1 or equal to the value of RXRTRRO (RBXnCON<3>) when EXID = 0. bit 3 EXID: Extended Identifier bit 1 = Received message is an extended data frame, SID10:SID0 are EID28:EID18 0 = Received message is a standard data frame bit 2 Unimplemented: Read as ‘0’ bit 1-0 EID17:EID16: Extended Identifier bits Legend: R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’ -n = Value at POR ‘1’ = Bit is set ‘0’ = Bit is cleared x = Bit is unknown R-x R-x R-x R-x R-x R-x R-x R-x EID15 EID14 EID13 EID12 EID11 EID10 EID9 EID8 bit 7 bit 0 bit 7-0 EID15:EID8: Extended Identifier bits Legend: R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’ -n = Value at POR ‘1’ = Bit is set ‘0’ = Bit is cleared x = Bit is unknown R-x R-x R-x R-x R-x R-x R-x R-x EID7 EID6 EID5 EID4 EID3 EID2 EID1 EID0 bit 7 bit 0 bit 7-0 EID7:EID0: Extended Identifier bits Legend: R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’ -n = Value at POR ‘1’ = Bit is set ‘0’ = Bit is cleared x = Bit is unknown |
|
