PIC18F2680ISPSQTP bảng dữ liệu(PDF) 57 Page - Microchip Technology |
|
|
|||||||||||||||||||||||||||||
PIC18F2680ISPSQTP bảng dữ liệu(HTML) 57 Page - Microchip Technology |
|
|
57 / 482 page  © 2007 Microchip Technology Inc. Preliminary DS39625C-page 55 PIC18F2585/2680/4585/4680 TXB2D1 2585 2680 4585 4680 xxxx xxxx uuuu uuuu 0uuu uuuu TXB2D0 2585 2680 4585 4680 xxxx xxxx uuuu uuuu 0uuu uuuu TXB2DLC 2585 2680 4585 4680 -x-- xxxx -u-- uuuu -u-- uuuu TXB2EIDL 2585 2680 4585 4680 xxxx xxxx uuuu uuuu uuuu uuuu TXB2EIDH 2585 2680 4585 4680 xxxx xxxx uuuu uuuu uuuu uuuu TXB2SIDL 2585 2680 4585 4680 xxxx x-xx uuuu u-uu -uuu uuuu TXB2SIDH 2585 2680 4585 4680 xxx- x-xx uuu- u-uu uuu- u-uu TXB2CON 2585 2680 4585 4680 0000 0-00 0000 0-00 uuuu u-uu RXM1EIDL 2585 2680 4585 4680 xxxx xxxx uuuu uuuu uuuu uuuu RXM1EIDH 2585 2680 4585 4680 xxxx xxxx uuuu uuuu uuuu uuuu RXM1SIDL 2585 2680 4585 4680 xxx- x-xx uuu- u-uu uuu- u-uu RXM1SIDH 2585 2680 4585 4680 xxxx xxxx uuuu uuuu uuuu uuuu RXM0EIDL 2585 2680 4585 4680 xxxx xxxx uuuu uuuu uuuu uuuu RXM0EIDH 2585 2680 4585 4680 xxxx xxxx uuuu uuuu uuuu uuuu RXM0SIDL 2585 2680 4585 4680 xxx- x-xx uuu- u-uu uuu- u-uu RXM0SIDH 2585 2680 4585 4680 xxxx xxxx uuuu uuuu uuuu uuuu RXF5EIDL 2585 2680 4585 4680 xxxx xxxx uuuu uuuu uuuu uuuu RXF5EIDH 2585 2680 4585 4680 xxxx xxxx uuuu uuuu uuuu uuuu RXF5SIDL 2585 2680 4585 4680 xxx- x-xx uuu- u-uu uuu- u-uu RXF5SIDH 2585 2680 4585 4680 xxxx xxxx uuuu uuuu uuuu uuuu RXF4EIDL 2585 2680 4585 4680 xxxx xxxx uuuu uuuu uuuu uuuu RXF4EIDH 2585 2680 4585 4680 xxxx xxxx uuuu uuuu uuuu uuuu RXF4SIDL 2585 2680 4585 4680 xxx- x-xx uuu- u-uu uuu- u-uu RXF4SIDH 2585 2680 4585 4680 xxxx xxxx uuuu uuuu uuuu uuuu RXF3EIDL 2585 2680 4585 4680 xxxx xxxx uuuu uuuu uuuu uuuu RXF3EIDH 2585 2680 4585 4680 xxxx xxxx uuuu uuuu uuuu uuuu RXF3SIDL 2585 2680 4585 4680 xxx- x-xx uuu- u-uu uuu- u-uu RXF3SIDH 2585 2680 4585 4680 xxxx xxxx uuuu uuuu uuuu uuuu RXF2EIDL 2585 2680 4585 4680 xxxx xxxx uuuu uuuu uuuu uuuu RXF2EIDH 2585 2680 4585 4680 xxxx xxxx uuuu uuuu uuuu uuuu RXF2SIDL 2585 2680 4585 4680 xxx- x-xx uuu- u-uu uuu- u-uu RXF2SIDH 2585 2680 4585 4680 xxxx xxxx uuuu uuuu uuuu uuuu TABLE 4-4: INITIALIZATION CONDITIONS FOR ALL REGISTERS (CONTINUED) Register Applicable Devices Power-on Reset, Brown-out Reset MCLR Resets, WDT Reset, RESET Instruction, Stack Resets Wake-up via WDT or Interrupt Legend: u = unchanged, x = unknown, - = unimplemented bit, read as ‘0’, q = value depends on condition. Shaded cells indicate conditions do not apply for the designated device. Note 1: One or more bits in the INTCONx or PIRx registers will be affected (to cause wake-up). 2: When the wake-up is due to an interrupt and the GIEL or GIEH bit is set, the PC is loaded with the interrupt vector (0008h or 0018h). 3: When the wake-up is due to an interrupt and the GIEL or GIEH bit is set, the TOSU, TOSH and TOSL are updated with the current value of the PC. The STKPTR is modified to point to the next location in the hardware stack. 4: See Table 4-3 for Reset value for specific condition. 5: Bits 6 and 7 of PORTA, LATA and TRISA are enabled, depending on the oscillator mode selected. When not enabled as PORTA pins, they are disabled and read ‘0’. 6: This register reads all ‘0’s until the ECAN™ technology is set up in Mode 1 or Mode 2. |
|
