PIC18F2585/2680/4585/4680

DS39625C-page 40

Preliminary

3.5.4

EXIT WITHOUT AN OSCILLATOR

START-UP DELAY

Certain exits from power managed modes do not

invoke the OST at all. There are two cases:

• PRI_IDLE mode where the primary clock source

is not stopped; and

• the primary clock source is not any of the LP, XT,

HS or HSPLL modes.

In these instances, the primary clock source either

does not require an oscillator start-up delay, since it is

already running (PRI_IDLE), or normally does not

require an oscillator start-up delay (RC, EC and INTIO

Oscillator modes). However, a fixed delay of interval

TCSD following the wake event is still required when

leaving Sleep and Idle modes to allow the CPU to pre-

pare for execution. Instruction execution resumes on

the first clock cycle following this delay.

TABLE 3-2:

EXIT DELAY ON WAKE-UP BY RESET FROM SLEEP MODE OR ANY IDLE MODE

(BY CLOCK SOURCES)

Clock Source

Before Wake-up

Clock Source

After Wake-up

Exit Delay

Clock Ready Status

Bit (OSCCON)

Primary Device Clock

(PRI_IDLE mode)

LP, XT, HS

TCSD(2)

OSTS

HSPLL

EC, RC

INTRC(1)

—

INTOSC(3)

IOFS

T1OSC or INTRC(1)

LP, XT, HS

TOST(4)

OSTS

HSPLL

TOST + trc

(4)

EC, RC

TCSD(2)

INTRC(1)

—

INTOSC(2)

TIOBST(5)

IOFS

INTOSC(3)

LP, XT, HS

TOST(5)

OSTS

HSPLL

TOST + trc

(4)

EC, RC

TCSD(2)

INTRC(1)

—

INTOSC(2)

None

IOFS

None

(Sleep mode)

LP, XT, HS

TOST(4)

OSTS

HSPLL

TOST + trc

(4)

EC, RC

TCSD(2)

INTRC(1)

—

INTOSC(2)

TIOBST(5)

IOFS

Note 1:

In this instance, refers specifically to the 31 kHz INTRC clock source.

TCSD (parameter 38) is a required delay when waking from Sleep and all Idle modes and runs concurrently

with any other required delays (see Section 3.4 “Idle Modes”).

Includes both the INTOSC 8 MHz source and postscaler derived frequencies.

TOST is the Oscillator Start-up Timer (parameter 32). trc is the PLL Lock-out Timer (parameter F12); it is

also designated as TPLL.

Execution continues during TIOBST (parameter 39), the INTOSC stabilization period.
