PIC18F2585/2680/4585/4680

DS39625C-page 288

Preliminary

bit 2

Mode 0:

RXB0DBEN: Receive Buffer 0 Double-Buffer Enable bit

= Receive Buffer 0 overflow will write to Receive Buffer 1

= No Receive Buffer 0 overflow to Receive Buffer 1

Mode 1, 2:

FILHIT2: Filter Hit bit 2

This bit combines with other bits to form filter acceptance bits <4:0>.

bit 1

Mode 0:

JTOFF: Jump Table Offset bit (read-only copy of RXB0DBEN)(2)

= Allows jump table offset between 6 and 7

= Allows jump table offset between 1 and 0

Mode 1, 2:

FILHIT1: Filter Hit bit 1

This bit combines with other bits to form filter acceptance bits <4:0>.

bit 0

Mode 0:

FILHIT0: Filter Hit bit 0

This bit indicates which acceptance filter enabled the message reception into Receive Buffer 0.

= Acceptance Filter 1 (RXF1)

= Acceptance Filter 0 (RXF0)

Mode 1, 2:

FILHIT0: Filter Hit bit 0

This bit, in combination with FILHIT<4:1>, indicates which acceptance filter enabled the

message reception into this receive buffer.

01111

= Acceptance Filter 15 (RXF15)

01110

= Acceptance Filter 14 (RXF14)

...

00000

= Acceptance Filter 0 (RXF0)

Note 1: This bit is set by the CAN module upon receiving a message and must be cleared

by software after the buffer is read. As long as RXFUL is set, no new message will

be loaded and buffer will be considered full. After clearing the RXFUL flag, the PIR3

bit, RXB0IF, can be cleared. If RXB0IF is cleared, but RXFUL is not cleared, then

RXB0IF is set again.

2: This bit allows same filter jump table for both RXB0CON and RXB1CON.

Legend:

C = Clearable bit

R = Readable bit W = Writable bit

U = Unimplemented bit, read as ‘0’

-n = Value at POR

‘1’ = Bit is set

‘0’ = Bit is cleared

x = Bit is unknown
