288 / 482 page  PIC18F2585/2680/4585/4680 DS39625C-page 286 Preliminary © 2007 Microchip Technology Inc. EXAMPLE 23-3: TRANSMITTING A CAN MESSAGE USING BANKED METHOD EXAMPLE 23-4: TRANSMITTING A CAN MESSAGE USING WIN BITS ; Need to transmit Standard Identifier message 123h using TXB0 buffer. ; To successfully transmit, CAN module must be either in Normal or Loopback mode. ; TXB0 buffer is not in access bank. And since we want banked method, we need to make sure ; that correct bank is selected. BANKSEL TXB0CON ; One BANKSEL in beginning will make sure that we are ; in correct bank for rest of the buffer access. ; Now load transmit data into TXB0 buffer. MOVLW MY_DATA_BYTE1 ; Load first data byte into buffer MOVWF TXB0D0 ; Compiler will automatically set “BANKED” bit ; Load rest of data bytes - up to 8 bytes into TXB0 buffer. ... ; Load message identifier MOVLW 60H ; Load SID2:SID0, EXIDE = 0 MOVWF TXB0SIDL MOVLW 24H ; Load SID10:SID3 MOVWF TXB0SIDH ; No need to load TXB0EIDL:TXB0EIDH, as we are transmitting Standard Identifier Message only. ; Now that all data bytes are loaded, mark it for transmission. MOVLW B’00001000’ ; Normal priority; Request transmission MOVWF TXB0CON ; If required, wait for message to get transmitted BTFSC TXB0CON, TXREQ ; Is it transmitted? BRA $-2 ; No. Continue to wait... ; Message is transmitted. ; Need to transmit Standard Identifier message 123h using TXB0 buffer. ; To successfully transmit, CAN module must be either in Normal or Loopback mode. ; TXB0 buffer is not in access bank. Use WIN bits to map it to RXB0 area. MOVF CANCON, W ; WIN bits are in lower 4 bits only. Read CANCON ; register to preserve all other bits. If operation ; mode is already known, there is no need to preserve ; other bits. ANDLW B’11110000’ ; Clear WIN bits. IORLW B’00001000’ ; Select Transmit Buffer 0 MOVWF CANCON ; Apply the changes. ; Now TXB0 is mapped in place of RXB0. All future access to RXB0 registers will actually ; yield TXB0 register values. ; Load transmit data into TXB0 buffer. MOVLW MY_DATA_BYTE1 ; Load first data byte into buffer MOVWF RXB0D0 ; Access TXB0D0 via RXB0D0 address. ; Load rest of the data bytes - up to 8 bytes into “TXB0” buffer using RXB0 registers. ... ; Load message identifier MOVLW 60H ; Load SID2:SID0, EXIDE = 0 MOVWF RXB0SIDL MOVLW 24H ; Load SID10:SID3 MOVWF RXB0SIDH ; No need to load RXB0EIDL:RXB0EIDH, as we are transmitting Standard Identifier Message only. ; Now that all data bytes are loaded, mark it for transmission. MOVLW B’00001000’ ; Normal priority; Request transmission MOVWF RXB0CON ; If required, wait for message to get transmitted BTFSC RXB0CON, TXREQ ; Is it transmitted? BRA $-2 ; No. Continue to wait... ; Message is transmitted. ; If required, reset the WIN bits to default state. |
|
