285 / 482 page  © 2007 Microchip Technology Inc. Preliminary DS39625C-page 283 PIC18F2585/2680/4585/4680 REGISTER 23-6: TXBnSIDH: TRANSMIT BUFFER n STANDARD IDENTIFIER REGISTERS, HIGH BYTE [0 ≤ n ≤ 2] REGISTER 23-7: TXBnSIDL: TRANSMIT BUFFER n STANDARD IDENTIFIER REGISTERS, LOW BYTE [0 ≤ n ≤ 2] REGISTER 23-8: TXBnEIDH: TRANSMIT BUFFER n EXTENDED IDENTIFIER REGISTERS, HIGH BYTE [0 ≤ n ≤ 2] R/W-x R/W-x R/W-x R/W-x R/W-x R/W-x R/W-x R/W-x SID10 SID9 SID8 SID7 SID6 SID5 SID4 SID3 bit 7 bit 0 bit 7-0 SID10:SID3: Standard Identifier bits (if EXIDE (TXBnSIDL<3>) = 0) Extended Identifier bits EID28:EID21 (if EXIDE = 1). Legend: R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’ -n = Value at POR ‘1’ = Bit is set ‘0’ = Bit is cleared x = Bit is unknown R/W-x R/W-x R/W-x U-0 R/W-x U-0 R/W-x R/W-x SID2 SID1 SID0 — EXIDE —EID17 EID16 bit 7 bit 0 bit 7-5 SID2:SID0: Standard Identifier bits (if EXIDE (TXBnSIDL<3>) = 0) Extended Identifier bits EID20:EID18 (if EXIDE = 1). bit 4 Unimplemented: Read as ‘0’ bit 3 EXIDE: Extended Identifier Enable bit 1 = Message will transmit extended ID, SID10:SID0 become EID28:EID18 0 = Message will transmit standard ID, EID17:EID0 are ignored bit 2 Unimplemented: Read as ‘0’ bit 1-0 EID17:EID16: Extended Identifier bits Legend: R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’ -n = Value at POR ‘1’ = Bit is set ‘0’ = Bit is cleared x = Bit is unknown R/W-x R/W-x R/W-x R/W-x R/W-x R/W-x R/W-x R/W-x EID15 EID14 EID13 EID12 EID11 EID10 EID9 EID8 bit 7 bit 0 bit 7-0 EID15:EID8: Extended Identifier bits (not used when transmitting standard identifier message) Legend: R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’ -n = Value at POR ‘1’ = Bit is set ‘0’ = Bit is cleared x = Bit is unknown |
|
