PIC18F2680ISPSQTP datasheet(127/482 Pages) MICROCHIP

127 / 482 page

Preliminary

DS39625C-page 125

PIC18F2585/2680/4585/4680

IPR2: PERIPHERAL INTERRUPT PRIORITY REGISTER 2

R/W-1

U-0

R/W-1

OSCFIP

CMIP(1)

—

EEIP

BCLIP

HLVDIP

TMR3IP

ECCP1IP(2)

bit 7

bit 0

bit 7

OSCFIP: Oscillator Fail Interrupt Priority bit

=High priority

= Low priority

bit 6

CMIP: Comparator Interrupt Priority bit(1)

=High priority

= Low priority

bit 5

Unimplemented: Read as ‘0’

bit 4

EEIP: Data EEPROM/Flash Write Operation Interrupt Priority bit

=High priority

= Low priority

bit 3

BCLIP: Bus Collision Interrupt Priority bit

=High priority

= Low priority

bit 2

HLVDIP: High/Low-Voltage Detect Interrupt Priority bit

=High priority

= Low priority

bit 1

TMR3IP: TMR3 Overflow Interrupt Priority bit

=High priority

= Low priority

bit 0

ECCP1IP: ECCP1 Interrupt Priority bit(2)

=High priority

= Low priority

Note 1: This bit is available in PIC18F4X8X devices and reserved in PIC18F2X8X devices.

2: This bit is available in PIC18F4X8X devices only.

Legend:

R = Readable bit

W = Writable bit

U = Unimplemented bit, read as ‘0’

-n = Value at POR

‘1’ = Bit is set

‘0’ = Bit is cleared

x = Bit is unknown
