DS39625C-page 121

PIC18F2585/2680/4585/4680

9.3

PIE Registers

The PIE registers contain the individual enable bits for

the peripheral interrupts. Due to the number of

peripheral interrupt sources, there are two Peripheral

Interrupt Enable registers (PIE1, PIE2). When IPEN = 0,

the PEIE bit must be set to enable any of these

peripheral interrupts.

PIE1: PERIPHERAL INTERRUPT ENABLE REGISTER 1

R/W-0

PSPIE(1)

ADIE

RCIE

TXIE

SSPIE

CCP1IE

TMR2IE

TMR1IE

bit 7

bit 0

bit 7

PSPIE: Parallel Slave Port Read/Write Interrupt Enable bit(1)

= Enables the PSP read/write interrupt

= Disables the PSP read/write interrupt

Note 1: This bit is reserved on PIC18F2X8X devices; always maintain this bit clear.

bit 6

ADIE: A/D Converter Interrupt Enable bit

= Enables the A/D interrupt

= Disables the A/D interrupt

bit 5

RCIE: EUSART Receive Interrupt Enable bit

= Enables the EUSART receive interrupt

= Disables the EUSART receive interrupt

bit 4

TXIE: EUSART Transmit Interrupt Enable bit

= Enables the EUSART transmit interrupt

= Disables the EUSART transmit interrupt

bit 3

SSPIE: Master Synchronous Serial Port Interrupt Enable bit

= Enables the MSSP interrupt

= Disables the MSSP interrupt

bit 2

CCP1IE: CCP1 Interrupt Enable bit

= Enables the CCP1 interrupt

= Disables the CCP1 interrupt

bit 1

TMR2IE: TMR2 to PR2 Match Interrupt Enable bit

= Enables the TMR2 to PR2 match interrupt

= Disables the TMR2 to PR2 match interrupt

bit 0

TMR1IE: TMR1 Overflow Interrupt Enable bit

= Enables the TMR1 overflow interrupt

= Disables the TMR1 overflow interrupt

Legend:

R = Readable bit

W = Writable bit

U = Unimplemented bit, read as ‘0’

-n = Value at POR

‘1’ = Bit is set

‘0’ = Bit is cleared

x = Bit is unknown
