PIC18F2585/2680/4585/4680

DS39625C-page 132

Preliminary

10.2

PORTB, TRISB and LATB

Registers

PORTB is an 8-bit wide, bidirectional port. The

corresponding data direction register is TRISB. Setting

a TRISB bit (= 1) will make the corresponding PORTB

pin an input (i.e., put the corresponding output driver in

a high-impedance mode). Clearing a TRISB bit (= 0)

will make the corresponding PORTB pin an output (i.e.,

put the contents of the output latch on the selected pin).

The Data Latch register (LATB) is also memory

mapped. Read-modify-write operations on the LATB

PORTB.

Pins RB2 through RB3 are multiplexed with the ECAN

peripheral. Refer to Section 23.0 “ECAN™ Technol-

ogy” for proper settings of TRISB when CAN is

enabled.

EXAMPLE 10-2:

INITIALIZING PORTB

Each of the PORTB pins has a weak internal pull-up. A

single control bit can turn on all the pull-ups. This is

performed by clearing bit RBPU (INTCON2<7>). The

weak pull-up is automatically turned off when the port

pin is configured as an output. The pull-ups are

disabled on all device Resets.

Four of the PORTB pins (RB7:RB4) have an interrupt-

on-change feature. Only pins configured as inputs can

cause this interrupt to occur (i.e., any RB7:RB4 pin

configured as an output is excluded from the interrupt-

on-change comparison). The input pins (of RB7:RB4)

are compared with the old value latched on the last

read of PORTB. The “mismatch” outputs of RB7:RB4

are ORed together to generate the RB Port Change

Interrupt with Flag bit, RBIF (INTCON<0>).

This interrupt can wake the device from Sleep. The

user, in the Interrupt Service Routine, can clear the

interrupt in the following manner:

Any read or write of PORTB (except with the

MOVFF

(ANY), PORTB

instruction). This will

end the mismatch condition.

Clear flag bit RBIF.

A mismatch condition will continue to set flag bit RBIF.

Reading PORTB will end the mismatch condition and

allow flag bit RBIF to be cleared.

The interrupt-on-change feature is recommended for

wake-up on key depression operation and operations

where PORTB is only used for the interrupt-on-change

feature. Polling of PORTB is not recommended while

using the interrupt-on-change feature.

Note:

On a Power-on Reset, RB4:RB0 are

configured as analog inputs by default and

read as ‘0’; RB7:RB5 are configured as

digital inputs.

By programming the Configuration bit,

PBADEN (CONFIG3H<1>), RB4:RB0 will

alternatively be configured as digital inputs

on POR.

CLRF

PORTB

; Initialize PORTB by

; clearing output

; data latches

CLRF

LATB

; Alternate method

; to clear output

; data latches

MOVLW

0Eh

; Set RB<4:0> as

MOVWF

ADCON1

; digital I/O pins

; (required if config bit

; PBADEN is set)

MOVLW

0CFh

; Value used to

; initialize data

; direction

MOVWF

TRISB

; Set RB<3:0> as inputs

; RB<5:4> as outputs

; RB<7:6> as inputs
