Preliminary

DS39625C-page 357

PIC18F2585/2680/4585/4680

24.5

Program Verification and

Code Protection

The overall structure of the code protection on the

PIC18 Flash devices differs significantly from other

PIC® devices.

The user program memory is divided into five blocks.

One of these is a boot block of 2 Kbytes. The remainder

of the memory is divided into four blocks on binary

boundaries.

Each of the five blocks has three code protection bits

associated with them. They are:

• Code-Protect bit (CPn)

• Write-Protect bit (WRTn)

• External Block Table Read bit (EBTRn)

Figure 24-5 shows the program memory organization

for 48 and 64-Kbyte devices and the specific code

protection bit associated with each block. The actual

locations of the bits are summarized in Table 24-3.

FIGURE 24-5:

CODE-PROTECTED PROGRAM MEMORY FOR PIC18F2585/2680/4585/4680

TABLE 24-3:

SUMMARY OF CODE PROTECTION REGISTERS

File Name

Bit 7

Bit 6

Bit 5

Bit 4

Bit 3

Bit 2

Bit 1

Bit 0

300008h

CONFIG5L

—

CP3*

CP2

CP1

CP0

300009h

CONFIG5H

CPD

CPB

—

30000Ah

CONFIG6L

—

WRT3*

WRT2

WRT1

WRT0

30000Bh

CONFIG6H

WRTD

WRTB

WRTC

—

30000Ch

CONFIG7L

—

EBTR3*

EBTR2

EBTR1

EBTR0

30000Dh

CONFIG7H

—

EBTRB

—

Legend: Shaded cells are unimplemented.

Unimplemented in PIC18FX585 devices; maintain this bit set.

MEMORY SIZE/DEVICE

Block Code Protection

Controlled By:

48 Kbytes

(PIC18F2585/4585)

64 Kbytes

(PIC18F2680/4680)

Address

Range

Boot Block

000000h

0007FFh

CPB, WRTB, EBTRB

Block 0

000800h

003FFFh

CP0, WRT0, EBTR0

Block 1

004000h

007FFFh

CP1, WRT1, EBTR1

Block 2

008000h

00B7FFh

CP2, WRT2, EBTR2

Unimplemented

Read ‘0’s

Block 3

00C000h

00FFFFh

CP3, WRT3, EBTR3

Unimplemented

Read ‘0’s

Unimplemented

Read ‘0’s

010000h

1FFFFFh

(Unimplemented Memory Space)
