Preliminary

DS39625C-page 339

PIC18F2585/2680/4585/4680

The PIC18F2585/2680/4585/4680 devices are error-

active if both error counters are below the error-passive

limit of 128. They are error-passive if at least one of the

error counters equals or exceeds 128. They go to bus-

off if the transmit error counter equals or exceeds the

bus-off limit of 256. The devices remain in this state

until the bus-off recovery sequence is received. The

bus-off recovery sequence consists of 128 occurrences

of 11 consecutive recessive bits (see Figure 23-8).

Note that the CAN module, after going bus-off, will

recover back to error-active without any intervention by

the MCU if the bus remains Idle for 128 x 11 bit times.

If this is not desired, the error Interrupt Service Routine

should address this. The current Error mode of the

CAN module can be read by the MCU via the

COMSTAT register.

Additionally, there is an Error State Warning flag bit,

EWARN, which is set if at least one of the error

counters equals or exceeds the error warning limit of

96. EWARN is reset if both error counters are less than

the error warning limit.

FIGURE 23-8:

ERROR MODES STATE DIAGRAM

23.15 CAN Interrupts

The module has several sources of interrupts. Each of

these interrupts can be individually enabled or

disabled. The PIR3 register contains interrupt flags.

The PIE3 register contains the enables for the 8 main

interrupts. A special set of read-only bits in the

CANSTAT register, the ICODE bits, can be used in

combination with a jump table for efficient handling of

interrupts.

All interrupts have one source, with the exception of the

error interrupt and buffer interrupts in Mode 1 and 2. Any

of the error interrupt sources can set the error interrupt

flag. The source of the error interrupt can be determined

reading

the

Communication

Status

COMSTAT. In Mode 1 and 2, there are two interrupt

enable/disable and flag bits – one for all transmit buffers

and the other for all receive buffers.

The interrupts can be broken up into two categories:

receive and transmit interrupts.

The receive related interrupts are:

• Receive Interrupts

• Wake-up Interrupt

• Receiver Overrun Interrupt

• Receiver Warning Interrupt

• Receiver Error-Passive Interrupt

The transmit related interrupts are:

• Transmit Interrupts

• Transmitter Warning Interrupt

• Transmitter Error-Passive Interrupt

• Bus-Off Interrupt

Bus-

Off

Error-

Active

Error-

Passive

RXERRCNT < 127 or

TXERRCNT < 127

RXERRCNT > 127 or

TXERRCNT > 127

TXERRCNT > 255

128 occurrences of

11 consecutive

“recessive” bits

Reset
