PIC18F2585/2680/4585/4680

DS39625C-page 182

Preliminary

16.4.6

PROGRAMMABLE DEAD-BAND

DELAY

In half-bridge applications where all power switches are

modulated at the PWM frequency at all times, the power

switches normally require more time to turn off than to

turn on. If both the upper and lower power switches are

switched at the same time (one turned on and the other

turned off), both switches may be on for a short period of

time until one switch completely turns off. During this

brief interval, a very high current (

shoot-through current)

may flow through both power switches, shorting the

bridge supply. To avoid this potentially destructive

shoot-through current from flowing during switching,

turning on either of the power switches is normally

delayed to allow the other switch to completely turn off.

In the Half-Bridge Output mode, a digitally program-

mable

dead-band

delay

available

avoid

shoot-through current from destroying the bridge

power switches. The delay occurs at the signal transi-

tion from the non-active state to the active state. See

Figure 16-4 for illustration. Bits PDC6:PDC0 of the

ECCP1DEL register (Register 16-2) set the delay

period in terms of microcontroller instruction cycles

(TCY or 4 TOSC). These bits are not available on

PIC18F2X8X devices, as the standard CCP1 module

does not support half-bridge operation.

16.4.7

ENHANCED PWM AUTO-SHUTDOWN

When the CCP1 is programmed for any of the Enhanced

PWM modes, the active output pins may be configured

for auto-shutdown. Auto-shutdown immediately places

the Enhanced PWM output pins into a defined shutdown

state when a shutdown event occurs.

A shutdown event can be caused by either of the

comparator

modules,

low

level

the

RB0/INT0/FLT0/AN10 pin, or any combination of these

three sources. The comparators may be used to monitor

a voltage input proportional to a current being monitored

in the bridge circuit. If the voltage exceeds a threshold,

the comparator switches state and triggers a shutdown.

Alternatively, a digital signal on the INT0 pin can also

trigger a shutdown. The auto-shutdown feature can be

disabled by not selecting any auto-shutdown sources.

The auto-shutdown sources to be used are selected

using the ECCPAS2:ECCPAS0 bits (bits<6:4> of the

ECCP1AS register).

When a shutdown occurs, the output pins are asyn-

chronously placed in their shutdown states, specified

by the PSSAC1:PSSAC0 and PSS1BD1:PSS1BD0

bits (ECCPAS3:ECCPAS0). Each pin pair (P1A/P1C

and P1B/P1D) may be set to drive high, drive low or be

tri-stated

(not

driving).

The

ECCPASE

bit

(ECCP1AS<7>) is also set to hold the Enhanced PWM

outputs in their shutdown states.

The ECCPASE bit is set by hardware when a shutdown

event occurs. If automatic restarts are not enabled, the

ECCPASE bit is cleared by firmware when the cause of

the shutdown clears. If automatic restarts are enabled,

the ECCPASE bit is automatically cleared when the

cause of the auto-shutdown has cleared.

If the ECCPASE bit is set when a PWM period begins,

the PWM outputs remain in their shutdown state for that

entire PWM period. When the ECCPASE bit is cleared,

the PWM outputs will return to normal operation at the

beginning of the next PWM period.

ECCP1DEL: PWM CONFIGURATION REGISTER

Note:

Programmable dead-band delay is not

implemented in PIC18F2X8X devices with

standard CCP1 modules.

Note:

Writing to the ECCPASE bit is disabled

while a shutdown condition is active.

R/W-0

PRSEN

PDC6(1)

PDC5(1)

PDC4(1)

PDC3(1)

PDC2(1)

PDC1(1)

PDC0(1)

bit 7

bit 0

bit 7

PRSEN: PWM Restart Enable bit

= Upon auto-shutdown, the ECCPASE bit clears automatically once the shutdown event

goes away; the PWM restarts automatically

= Upon auto-shutdown, ECCPASE must be cleared in software to restart the PWM

bit 6-0

PDC6:PDC0: PWM Delay Count bits(1)

Delay time, in number of FOSC/4 (4 * TOSC) cycles, between the scheduled and actual time for

a PWM signal to transition to active.

Note 1: Reserved on PIC18F2X8X devices; maintain these bits clear.

Legend:

R = Readable bit

W = Writable bit

U = Unimplemented bit, read as ‘0’

-n = Value at POR

‘1’ = Bit is set

‘0’ = Bit is cleared

x = Bit is unknown
