Preliminary

DS39625C-page 373

PIC18F2585/2680/4585/4680

BRA

Unconditional Branch

Syntax:

BRA

Operands:

-1024

≤ n ≤ 1023

Operation:

(PC) + 2 + 2n

→ PC

Status Affected:

None

Encoding:

1101

0nnn

nnnn

Description:

Add the 2’s complement number ‘2n’ to

the PC. Since the PC will have

incremented to fetch the next

instruction, the new address will be

PC + 2 + 2n. This instruction is a

two-cycle instruction.

Words:

Cycles:

Q Cycle Activity:

Decode

Read literal

‘n’

Process

Data

Write to PC

operation

Example:

HERE

BRA

Jump

Before Instruction

address (HERE)

After Instruction

address (Jump)

BSF

Bit Set f

Syntax:

BSF

f, b {,a}

Operands:

≤ f ≤ 255

≤ b ≤ 7

∈ [0,1]

Operation:

→ f<b>

Status Affected:

None

Encoding:

1000

bbba

ffff

Description:

Bit ‘b’ in register ‘f’ is set.

If ‘a’ is ‘0’, the Access Bank is selected.

If ‘a’ is ‘1’, the BSR is used to select the

GPR bank (default).

If ‘a’ is ‘0’ and the extended instruction

set is enabled, this instruction operates

in Indexed Literal Offset Addressing

mode whenever f

≤ 95 (5Fh). See

Section 25.2.3 “Byte-Oriented and

Bit-Oriented Instructions in Indexed

Literal Offset Mode” for details.

Words:

Cycles:

Q Cycle Activity:

Decode

Read

Process

Data

Write

Example:

BSF

FLAG_REG, 7, 1

Before Instruction

FLAG_REG

0Ah

After Instruction

FLAG_REG

8Ah
