Preliminary

DS39625C-page 323

PIC18F2585/2680/4585/4680

TABLE 23-1:

CAN CONTROLLER REGISTER MAP (CONTINUED)

Address(1)

Name

D7Fh

—(4)

D7Eh

—(4)

D7Dh

—(4)

D7Ch

—(4)

D7Bh

RXF11EIDL

D7Ah

RXF11EIDH

D79h

RXF11SIDL

D78h

RXF11SIDH

D77h

RXF10EIDL

D76h

RXF10EIDH

D75h

RXF10SIDL

D74h

RXF10SIDH

D73h

RXF9EIDL

D72h

RXF9EIDH

D71h

RXF9SIDL

D70h

RXF9SIDH

D6Fh

—(4)

D6Eh

—(4)

D6Dh

—(4)

D6Ch

—(4)

D6Bh

RXF8EIDL

D6Ah

RXF8EIDH

D69h

RXF8SIDL

D68h

RXF8SIDH

D67h

RXF7EIDL

D66h

RXF7EIDH

D65h

RXF7SIDL

D64h

RXF7SIDH

D63h

RXF6EIDL

D62h

RXF6EIDH

D61h

RXF6SIDL

D60h

RXF6SIDH

Note 1:

Shaded registers are available in Access Bank low area while the rest are available in Bank 15.

CANSTAT register is repeated in these locations to simplify application firmware. Unique names are given

for each instance of the controller register due to the Microchip header file requirement.

These registers are not CAN registers.

Unimplemented registers are read as ‘0’.
