Preliminary

DS39625C-page 313

PIC18F2585/2680/4585/4680

R/W-0

U-0

R/W-0

WAKDIS

WAKFIL

—

SEG2PH2(1) SEG2PH1(1) SEG2PH0(1)

bit 7

bit 0

bit 7

WAKDIS: Wake-up Disable bit

= Disable CAN bus activity wake-up feature

= Enable CAN bus activity wake-up feature

bit 6

WAKFIL: Selects CAN bus Line Filter for Wake-up bit

= Use CAN bus line filter for wake-up

= CAN bus line filter is not used for wake-up

bit 5-3

Unimplemented: Read as ‘0’

bit 2-0

SEG2PH2:SEG2PH0: Phase Segment 2 Time Select bits(1)

111

= Phase Segment 2 time = 8 x TQ

110

= Phase Segment 2 time = 7 x TQ

101

= Phase Segment 2 time = 6 x TQ

100

= Phase Segment 2 time = 5 x TQ

011

= Phase Segment 2 time = 4 x TQ

010

= Phase Segment 2 time = 3 x TQ

001

= Phase Segment 2 time = 2 x TQ

000

= Phase Segment 2 time = 1 x TQ

Note 1: Ignored if SEG2PHTS bit (BRGCON2<7>) is ‘0’.

Legend:

R = Readable bit

W = Writable bit

U = Unimplemented bit, read as ‘0’

- n = Value at POR

‘1’ = Bit is set

‘0’ = Bit is cleared

x = Bit is unknown
