PIC18F2585/2680/4585/4680

DS39625C-page 300

Preliminary

≤ n ≤ 5, TXnEN (BSEL<n>) = 0](1)

U-0

R-x

—

RXRTR

RB1

RB0

DLC3

DLC2

DLC1

DLC0

bit 7

bit 0

bit 7

Unimplemented: Read as ‘0’

bit 6

RXRTR: Receiver Remote Transmission Request bit

= This is a remote transmission request

= This is not a remote transmission request

bit 5

RB1: Reserved bit 1

Reserved by CAN Spec and read as ‘0’.

bit 4

RB0: Reserved bit 0

Reserved by CAN Spec and read as ‘0’.

bit 3-0

DLC3:DLC0: Data Length Code bits

1111

= Reserved

1110

= Reserved

1101

= Reserved

1100

= Reserved

1011

= Reserved

1010

= Reserved

1001

= Reserved

1000

= Data length = 8 bytes

0111

= Data length = 7 bytes

0110

= Data length = 6 bytes

0101

= Data length = 5 bytes

0100

= Data length = 4 bytes

0011

= Data length = 3 bytes

0010

= Data length = 2 bytes

0001

= Data length = 1 bytes

0000

= Data length = 0 bytes

Note 1: These registers are available in Mode 1 and 2 only.

Legend:

R = Readable bit

W = Writable bit

U = Unimplemented bit, read as ‘0’

-n = Value at POR

‘1’ = Bit is set

‘0’ = Bit is cleared

x = Bit is unknown
