MSC8152 Dual-Core Digital Signal Processor Data Sheet, Rev. 1
Freescale Semiconductor
10
H25
SXCVSS1
Ground
N/A
H26
SXCVDD1
Power
N/A
H27
SR1_RXD3/SG2_RX4
I
SXCVDD1
H28
SR1_RXD3/SG2_RX4
I
SXCVDD1
J1
M2DQS1
I/O
GVDD2
J2
M2DQS1
I/O
GVDD2
J3
M2DQ10
I/O
GVDD2
J4
M2DQ11
I/O
GVDD2
J5
M2DQ14
I/O
GVDD2
J6
M2DQ23
I/O
GVDD2
J7
M2ODT0
OGVDD2
J8
M2A12
OGVDD2
J9
M2A14
OGVDD2
J10
VSS
Ground
N/A
J11
GVDD2
Power
N/A
J12
VSS
Ground
N/A
J13
GVDD2
Power
N/A
J14
VSS
Ground
N/A
J15
GVDD2
Power
N/A
J16
VSS
Ground
N/A
J17
GVDD2
Power
N/A
J18
VSS
Ground
N/A
J19
GVDD2
Power
N/A
J20
Reserved
NC
—
J21
Reserved
NC
—
J22
Reserved
NC
—
J23
SXPVDD1
Power
N/A
J24
SXPVSS1
Ground
N/A
J25
SXCVDD1
Power
N/A
J26
SXCVSS1
Ground
N/A
J27
SXCVDD1
Power
N/A
J28
SXCVSS1
Ground
N/A
K1
VSS
Ground
N/A
K2
GVDD2
Power
N/A
K3
M2DM1
OGVDD2
K4
VSS
Ground
N/A
K5
GVDD2
Power
N/A
K6
M2DQ0
I/O
GVDD2
K7
VSS
Ground
N/A
K8
GVDD2
Power
N/A
K9
M2DQ5
I/O
GVDD2
K10
VSS
Ground
N/A
K11
VDD
Power
N/A
K12
VSS
Ground
N/A
K13
VDD
Power
N/A
K14
VSS
Ground
N/A
Table 1. Signal List by Ball Number (continued)
Ball Number
Signal Name1,2
Pin Type10
Power Rail
Name
