MSC8152 Dual-Core Digital Signal Processor Data Sheet, Rev. 1

Product Documentation

Freescale Semiconductor

Product Documentation

Following is a general list of supporting documentation:

•

MSC8152 Technical Data Sheet (MSC8152). Details the signals, AC/DC characteristics, clock signal characteristics,

package and pinout, and electrical design considerations of the MSC8152 device.

•

MSC8152 Reference Manual (MSC8152RM). Includes functional descriptions of the extended cores and all the

internal subsystems including configuration and programming information.

•

Application Notes. Cover various programming topics related to the StarCore DSP core and the MSC8152 device.

•

QUICC Engine Block Reference Manual with Protocol Interworking (QEIWRM). Provides detailed information

regarding the QUICC Engine technology including functional description, registers, and programming information.

•

SC3850 DSP Core Reference Manual. Covers the SC3850 core architecture, control registers, clock registers, program

control, and instruction set.

•

MSC8156SC3850 DSP Core Subsystem Reference Manual. Covers core subsystem architecture, functionality, and

registers.

Revision History

Table 50 provides a revision history for this data sheet.

Table 50. Document Revision History

Rev.

Date

Description

Jun. 2010

• Initial public release.

Dec 2010

• Updated Table 16.

• Updated Section 3.1.2, Power-On Ramp Time.
