Low-Power, Active Energy, Polyphase AFE
______________________________________________________________________________________
77
Linearity Compensation
Linearity Offset, High Range, Phase X = A/B/C (X.OFFS_HI) (A: 0x138, B: 0x224, C: 0x310)
This signed register contains the linearity offset for phase X current channel when the programmable gain amplifier
is set to unity gain (that is, the measured current is above the low current threshold). The signed value represented
by this register is added to the current value according to following formula:
if LINFRM = 0:
if LINFRM = 1: X.IRMS + X.OFFS_HI x 24
Linearity Gain Coefficient, Low Range, Phase X = A/B/C (X.GAIN_LO)
(A: 0x13A, B: 0x226, C: 0x312)
This register contains the linearity coefficient for phase X current channel when the programmable gain amplifier is
set to gain of 32 (that is, the measured current is below the low current threshold). The effective gain is given by the
equation:
XGAIN LO
._
214
X IRMS
X OFFS HI
..
_
224
2
+×
Bit:
15
14
13
12
11
10
9
8
Name:
Linearity Offset High Byte
Reset:
0x00
Bit:
7
6
5
4
3
2
1
0
Name:
Linearity Offset Low Byte
Reset:
0x00
Bit:
15
14
13
12
11
10
9
8
Name:
Linearity Coefficient High Byte
Reset:
0x40
Bit:
7
6
5
4
3
2
1
0
Name:
Linearity Coefficient Low Byte
Reset:
0x00
