CC1110 PRELIMINARY Datasheet (Rev. 1.01) SWRS033A

Page 13 of 202

7.1

General Characteristics

TA=25°C, VDD=3.0V if nothing else stated.

Parameter

Min

Typ

Max

Unit

Condition/Note

Wake-Up and Timing

Power mode 1

power

mode 0 (active)

Digital regulator on, High Speed RCOSC or crystal

oscillator running. Entry from PM1 to PM0 takes

one clock period.

Power mode 2 or 3

power mode 0 (active)

µs

Digital regulator off, High Speed RCOSC and

crystal oscillator off. Start-up of regulator and High

Speed RCOSC.

Active

26 MHz XOSC initially OFF

495

µs

Digital regulator on. Crystal oscillator off. Start-up

of crystal oscillator and RF TX/RX begins.

Active

26 MHz XOSC initially OFF

495

µs

Digital regulator on. Crystal oscillator off. Start-up

of crystal oscillator and RF TX/RX begins.

Active

195

µs

Digital regulator on. Crystal oscillator on. Time

from enabling radio until RX begins.

Active

195

µs

Digital regulator on. Crystal oscillator on. Time

from enabling radio until TX begins.

Radio part

Frequency range

300

348

MHz

400

464

MHz

800

928

MHz

Data rate

1.2

500

kbps

Modulation formats supported:

(Shaped) MSK (also known as differential offset

QPSK) up to 500kbps

2-FSK up to 500kbps

GFSK and OOK/ASK (up to 250kbps)

Optional Manchester encoding (halves the data

rate)

Data rate must be selected to comply with

frequency regulations.

Table 5: General Characteristics
