DS31256 256-Channel, High-Throughput HDLC Controller

95 of 183

Status/Interrupts

On each read of the free queue by the DMA, the DMA sets either the status bit for receive DMA large

buffer read (RLBR) or the status bit for receive DMA small buffer read (RSBR) in the status register for

DMA (SDMA). The DMA also checks the receive free-queue large-buffer host write pointer and the

receive free-queue small-buffer host write pointer to ensure that an underflow does not occur. If it does

occur, the DMA sets either the status bit for receive DMA large buffer read error (RLBRE) or the status

bit for receive DMA small buffer read error (RSBRE) in the status register for DMA (SDMA), and it

does not read the free queue nor does it increment the read pointer. In such a scenario, the receive FIFO

can overflow if the host does not provide free-queue descriptors. Each of the status bits can also (if

enabled) cause a hardware interrupt to occur. See Section 5 for more details.

Free-Queue Burst Reading

The DMA can read the free queue in bursts, which allows for a more efficient use of the PCI bus. The

DMA can grab messages from the free queue in groups rather than one at a time, freeing up the PCI bus

for more time-critical functions.

An internal FIFO stores up to 16 free-queue descriptors (32 dwords, as each descriptor occupies two

dwords). The free queue can either opeate in dual or singular circular queue mode. It can be divided into

large buffer and small buffer. The LBSA (large buffer starting address) and the LBEA (large buffer

ending address) form the large buffer queue, and the SBSA (small buffer starting address) and the

RFQEA (receive free-queue end address) form the small buffer queue. When the SBSA is not equal to

and greater than the RFQEA, the free queue is set up in a dual circular mode. If the SBSA is equal to the

FRQEA, the free queue is operating in a single queue mode. When the free queue is operated as a dual

circular queue supporting both large and small buffers, then the FIFO is cut into two 8-message FIFOs. If

the free queue is operated as a single circular queu supporting only the large buffers, then the FIFO is set

up as a single 16-descriptor FIFO. The host must configure the free-queue FIFO for proper operation

through the receive DMA queues control (RDMAQ) register (see the following).

When enabled through the receive free-queue FIFO-enable (RFQFE) bit, the free-queue FIFO does not

read the free queue until it reaches the low watermark. When the FIFO reaches the low watermark

(which is two descriptors in the dual mode or four descriptors in the single mode), it attempts to fill the

FIFO with additional descriptors by burst reading the free queue. Before it reads the free queue, it checks

(by examining the receive free-queue host write pointer) to ensure the free queue contains enough

descriptors to fill the free-queue FIFO. If the free queue does not have enough descriptors to fill the

FIFO, it only reads enough to keep from underflowing the free queue. If the FIFO detects that there are

no free-queue descriptors available for it to read, then it sets either the status bit for the receive DMA

large buffer read error (RLBRE) or the status bit for the receive DMA small buffer read error (RSBRE)

in the status register for DMA (SDMA); it does not read the free queue nor does it increment the read

pointer. In such a scenario, the receive FIFO can overflow if the host does not provide free-queue

descriptors. If the free-queue FIFO can read descriptors from the free queue, it burst reads them,

increments the read pointer, and sets either the status bit for receive DMA large buffer read (RLBR) or

the status bit for the receive DMA small buffer read (RSBR) in the status register for DMA (SDMA).

See Section 5 for more details on status bits.
