C-9

www.ittcannon.com

Dimensions shown in inches (mm)

Specifications and dimensions subject to change

Cannon Solder Cup, Size 20

Military/Hi-Reliability

Solder Cup

Dimensions

Plug

• For contact cavity arrangements, see pages C-44.

• For panel cutouts, see page C-49.

• Accepts up to 18 AWG.

Shell

size ± 0,38 (.015) ± 0,13 (.005) ± 0,13 (.005) ± 0,13 (.005) ± 0,38 (.015) ± 0,25 (.010) ± 0,368 (.0145) ± 0,41 (.016) ± 0,317 (.0125) ± 0,25 (.010) ± 0,25

(.010)

30,81 (1.213)

16,92 (.666)

24,99 (8,36)

8,36 (.329)

12,55 (.494)

10,72 (.422)

6,693 (.2635)

1,206 (.0475)

0,76 (.030)

39,14 (1.541)

25,25 (.994)

33,32 (1.312)

8,36 (.329)

12,55 (.494)

10,72 (.422)

6,693 (.2635)

1,206 (.0475)

0,76 (.030)

53,04 (2.088)

38,96 (1.534)

47,04 (1.852)

8,36 (.329)

12,55 (.494)

10,82 (.426)

6.84 (.269)

1,52 (.060)

0,99 (.039)

69,32 (2.729)

55,42 (2.182)

63,50 (2.500)

8,36 (.329)

12,55 (.494)

10,82 (.426)

6.84 (.269)

1,52 (.060)

0,99 (.039)

66,93 (2.635)

52,81 (2.079)

61,11 (2.406)

11,07 (.436)

15,37 (.605)

10,82 (.426)

6.84 (.269)

1,52 (.060)

0,99 (.039)

Shell Size

Layout

Through Hole

Dual Float Mount

DEM9P

DEMY9P

DAM15P

DAMY15P

DBM25P

DBMY25P

DCM37P

DCMY37P

DDM50P

DDMY50P

Note: For residual magnetism level of 200 gamma and shells and contacts with 50 mi-

croinches (1,27 m) gold plating, add NMBK52"

Engaging Face

DD Configuration

Ø 3,05

(.120)

5,69

(.224)

2,84

(.112)

Size D

10,72 (.422)

MAX

2,84

(.112)

Sizes E, A, B, C
