Cannon Combo D® Coax 90° PCB Plug DD

Military/High Reliability

Coaxial 90° PCB Plug, sizes DD, with metal bracket

C-30

www.ittcannon.com

Dimensions shown in inches (mm)

Specifications and dimensions subject to change

Engaging Face

Screw lock, boardlock, and coaxial contact

removed for clarity

Screw lock, boardlock, and signal contacts

removed for clarity

11,53 ± 0,25

(.454 ± .010)

5,68

(.224)

2,84

(.112)

4,33 ± 0,38

(.170 ± .015)

RIVNUT

#4-40 UNC

3,89 (.153)

MIN

11,94 ± 0,33

(.470 ± .013)

2,54

(.100)

Ø 0,51

(.020)

0,56

(.023)

6,50 ± 0,25

(.256 ± .010)

13,74

(.541)

10,06

(.396)

SCREW LOCK

#4-40 UNC

BRACKET,

METAL

Ø 0,76

(.030)

0,82

(.032)

2,92

(.115)

BOARDLOCK

10°

INDUSTRIAL – US

INDUSTRIAL – EU**

MILITARY/HI-REL – US

NON-MAGNETIC/LOW OUTGASSING-EU***

75 Ohm* coax inserted with

50 Ohm* coax inserted with

US footprint metal bracket

EU footprint metal bracket

US footprint metal bracket

and UNC 4-40 captive nut

and UNC 4-40 screw lock

Shell Layout P/N without

P/N with

P/N without

P/N with

P/N without

P/N with

size

Boardlock

Gold Plating

24W7

DDMP24C7P-JK87

DDMC24C7P-JK87

DDMP24C7P-VK87

DDMC24C7P-VK87

DDMMD24X7P-J

DDMMG24X7P-J

DDM24X7P-JNMBK52

36W4

DDMP36C4P-JK87

DDMC36C4P-JK87

DDMP36C4P-VK87

DDMC36C4P-VK87

DDMMD36X4P-J

DDMMG36X4P-J

DDM36X4P-JNMBK52

43W2

DDMP43C2P-JK87

DDMC43C2P-JK87

DDMP43C2P-VK87

DDMC43C2P-VK87

DDMMD43X2P-J

DDMMG43X2P-J

DDM43X2P-JNMBK52

47W1

DDMP47C1P-JK87

DDMC47C1P-JK87

DDMP47C1P-VK87

DDMC47C1P-VK87

DDMMD47X1P-J

DDMMG47X1P-J

DDM47X1P-JNMBK52

* For 50 ohm coaxial inserts replace C with X, e.g.:DCM13C6P-J becomes DCM13X6P-J.

**For M-3 hardware, see Combo D Catalog.

*** Hardware Modifier not allowed with Non Magnetic/ Low Outgassing Combo-D- Contact factory for more information

US version shown – for EU version, please contact factory.

For 50 ohm coaxial version, see Combo D Catalog

Note: Dimension varies with alternate bracket configuration, see Combo D Catalog.

Shell

size

± 0,38 (.015)

± 0,13 (.005)

± 0,38 (.015)

± 0,25 (.010)

± 0,41 (.015)

± 0,25 (.010)

66,93 (2.635)

52,81 (2.079)

61,11 (2,406)

11,07 (.436)

15,37 (.605)

10,82 (.426)

6,84 (.269)

0,99 (.039)

Dimensions

• For contact cavity arrangements, see page C-43.

• For pcb hole pattern, see Combo D Catalog.

Plug
