Cannon Combo D® Coax 90° PCB Receptacle DD

Military/High Reliability

Coaxial 90° PCB Receptacle, Size DD, with metal bracket

C-32

www.ittcannon.com

Dimensions shown in inches (mm)

Specifications and dimensions subject to change

INDUSTRIAL – US

INDUSTRIAL – EU**

MILITARY/HI-REL – US

NON-MAGNETIC/LOW OUTGASSING – US***

75 Ohm* coax inserted with

US Footprint metal bracket

EU Footprint metal bracket

US Footprint metal bracket

and UNC 4-40 captive nut

and UNC 4-40 screw lock

Shell Layout P/N without

P/N with

P/N without

P/N with

P/N without

P/N with

size

Boardlock

Gold Plating

24W7

DDMP24C7S-JA197

DDMC24C7S-JA197

DDMP24C7S-VA197

DDMC24C7S-VA197

DDMMD24X7S-J

DDMMG24X2S-J

DDM24X7S-JNMBK52

36W4

DDMP36C4S-JA197

DDMC36C4S-JA197

DDMP36C4S-VA197

DDMC36C4S-VA197

DDMMD36X4S-J

DDMMG36X1S-J

DDM36X4S-JNMBK52

43W2

DDMP43C2S-JA197

DDMC43C2S-JA197

DDMP43C2S-VA197

DDMC43C2S-VA197

DDMMD43X2S-J

DDMMG43X2S-J

DDM43X2S-JNMBK52

47W1

DDMP47C1S-JA197

DDMC47C1S-JA197

DDMP47C1S-VA197

DDMC47C1S-VA197

DDMMD47X1S-J

DDMMG47X1S-J

DDM47X1S-JNMBK52

* For 50 ohm coaxial inserts replace C with X, e.g.:DCM13C6 becomes DCM13X6S-JA197

**For M-3 and other hardware options, see Combo D Catalog.

*** Hardware Modifier not allowed with Non Magnetic/ Low Outgassing Combo-D- Contact factory for more information

• For contact cavity arrangements, see page C-43.

• For pcb hole pattern, see Combo D Catalog..

Shell

size

± 0,38 (.015)

± 0,13 (.005)

± 0,38 (.015)

± 0,25 (.010)

± 0,38 (.015)

± 0,25 (.010)

66,93 (2.635)

52,42 (2.064)

61,11 (2,406)

10,74 (.423)

15,37 (.605)

10,90 (.429)

6,94 (.273)

0,76 (.030)

Dimensions

US version shown – for EU version, please see Combo D Catalog.

For 50 ohm coaxial version, see Combo D Catalog.

Note: Dimension varies with alternate bracket configuration.

Receptacle

Engaging Face

Screw lock, boardlock, and coaxial contacts

removed for clarity

Screw lock, boardlock, and signal contacts

removed for clarity

5,68

(.224)

11,53 ± 0,25

(.454 ± .010)

4,33 ± 0,38

(.170 ± .015)

2,84 (.112)

RIVNUT

#4-40 UNC

3,89 (.153)

MIN

0,56

(.023)

Ø 0,51

(.020)

2,54

(.100)

11,94 ± 0,33

(.470 ± .013)

Ø 0,76

(.030)

0,82

(.032)

10°

2,92

(.115)

BOARDLOCK

6,50 ± 0,25

(.256 ± .010)

13,74

(.541)

10,06

(.396)

BRACKET,

METAL

SCREW LOCK

#4-40 UNC

ca_C1-C61.qxd:Layout 1

2/10/11

9:32 AM

Page 32
