D*M Combo D-Subminiature

Connector Designator for High Reliability Applications

Solder Cup, Crimp, and PCB Type, Combo-D’s with Machined Contacts

Typical Part Number:

DBM

C 13X3 S J 101

Product Family Designator

D*M

= Solder Cup & Std. Density PCB

Industrial/Commercial Version

D*MM = Solder Cup & PCB Mil version

(50 micro-inch gold contact/plating)

D*A

= Crimp signal contacts

Hardware Modifier*

=0.120” (3,05mm) Through Hole

B =4-40 Female Screwlock

C =90° Metal Bracket, 4-40 Fastener, & Boardlock (D*M, D*MM Only)

D =90° Metal Bracket, 4-40 Fastener and 4-40 Screwlock (D*M, D*MM Only)

E =4-40 Clinchnut

G =90° Metal Bracket, 4-40 Fastener, 4-40 Screwlock, Boardlock (D*M, D*MM)

H =.300” (7.6mm) Standoff, 4-40 Screwlock (D*M, D*MM US Only)

I = 90° metal bracket, .120" (3.05mm) through hole

K =0.162” (4,11mm) Through Hole

N =.300” (7.6mm) Standoff, 4-40 Screwlock, Boardlock (D*M, D*MM Only)

P =90° Metal Bracket, 4-40 Fastener (D*M, D*MM)

S =90° Metal Bracket, M-3 Fastener (D*M, D*MM)

V =.300” (7.6mm) 4-40 Standoff (D*M, D*MM Only)

X =M3 clinchnut

Y =Dual Float Mount

Z =.300” (7.6mm) 4-40 Standoff, Boardlock (D*M, D*MM Only)

* =Shell Sizes are E, A, B, C, D

* Note: Combo-D hardware and finishes are available on D*M standard density

9, 15, 25, 37 and 50 position connectors

• Shell Modifier (Standard)*

= Yellow chromate over zinc shells

A101 = Yellow Chromate over Cadmium shells

F225 = Stainless steel shells (RoHS) (Non Hardware Versions Only)

A197 = Pure Tin over Nickel Shells (Sockets only, RoHS through hole ver-

sions only)

K87 = Pure Tin over Nickel Shells w/grounding dimples (Pins only, RoHS)

• PC Tail Modifier (Standard)*

= Solder Cup (D*M/D*MM; Crimp, D*MA, D*MAM)

J = 90° Std. PCB signal contact (.170" lg by .030" )

N = Straight Std. PCB signal contact (.178" lg by .030 Ø)

V = 90° Euro PCB signal contact (.157" lg by .024 Ø)

Y = Straight Euro PCB signal contact (.178" lg by .024 Ø)

• Gender

P = Male Plug, Pin

S = Female Receptacle, Socket

• Layouts - *Combo D E-2W2; 2WK2K, 9

(D*M) A- 5W1; A- 3W3, 3WK3, 7W2, 11W1, 95

B- 5W5, 9W4, 13W3, 17W2, 21W1, 25

C- 8W8, 13W6, 17W5, 21WA4, 25W3, 27W2, 37

D- 24W7, 36W4, 43W2, 47W1, 50

Combo-D Size 8 Contact Designators:

W = w/o Contacts (letters below denote with contacts)

C = 75 Ohm Coax Contacts Installed, stamped

X = 50 Ohm Coax Contacts Installed, stamped

H = High Power Installed

V = High Voltage Installed (Cable and straight PCB only)

R = Mini Hi Power 90° Installed

F = Fiber Optic

G= Guide Pin

P = High Power Installed (European)

M = 50 ohm coax contact installed, machined, 50 microinches gold

N = 50 ohm coax contact installed, machined, 30 microinches gold
