background image
Datasheet
7
002-37178 Rev. *B
2023-10-10
EZ-PD™ PAG2S-PS integrated USB PD and
synchronous-rectification controller
Pinouts
Table 2
24-pin SOIC pin description
Pin number Pin name
Pin description
1
CC_COMP_GPIO0
Compensation pin/GPIO/TCPWM
2
VBUS_IN
Power source input for regulator
3
VCCD
1.8 V core voltage LDO output
4
VDDD
3.0 V to 5.5 V internal LDO output
5VSS
Ground
6
VDDD_SR
VDDD supply for sync rectifier driver
7
SR_CPN
Synchronous-rectification doubler capacitor negative pin
8
SR_CPP
Synchronous-rectification doubler capacitor positive pin
9
VSS_SR
Ground for sync rectifier driver
10
SR_GDRV
Synchronous-rectifier NFET gate driver
11
SR_SEN
Synchronous-rectifier NFET drain terminal sensing
12
SR_CAP
Synchronous-rectifier NFET high frequency sensing input for fast ZCD
13
DM_GPIO1
USB D–/GPIO/SWD_DAT
14
DP_GPIO2
USB D+/GPIO/SWD_CLK
15
GPIO3
External reset input/GPIO
16
CC2
Power Delivery Communication Channel 2
17
CC1
Power Delivery Communication Channel 1
18
CSN
Low-side current sense amplifier negative input
19
CSP
Low-side current sense amplifier positive input
20
VBUS_C
USB Type-C VBUS monitor input
21
VBUS_CTRL
Load switch NFET gate control
22
EA_OUT
Error amplifier output
23
FB
Error amplifier feedback
24
CC_COMP_GPIO4
Compensation pin/GPIO
