CC1110 PRELIMINARY Datasheet (Rev. 1.01) SWRS033A

Page 22 of 202

7.15 Timer Inputs AC Characteristics

TA =85°C, VDD=3.0V if nothing else stated. Measured on Chipcon’s CC1110 EM reference design.

Parameter

Min

Typ

Max

Unit

Condition/Note

Input capture

pulse width

tSYSCLK

Synchronizers determine the shortest input pulse that

can be recognized. The synchronizers operate from the

current system clock rate

Table 19: Timer Inputs AC Characteristics

7.16 DC Characteristics

The DC Characteristics of

CC1110 are listed in Table 20 below.

TA=25°C, VDD=3.0V if nothing else stated. Measured on Chipcon’s CC1110 EM reference design.

Digital Inputs/Outputs

Min

Typ

Max

Unit

Condition

Logic "0" input voltage

0.7

0.9

Logic "1" input voltage

VDD-0.25

VDD

Logic "0" output voltage

0.25

For up to 4mA output current on all pins except

P1_0 and P1_1 which are up to 20 mA

Logic "1" output voltage

VDD-0.25

VDD

For up to 4mA output current on all pins except

P1_0 and P1_1 which are up to 20 mA

Logic "0" input current

N/A

–1

µA

Input equals 0V

Logic "1" input current

N/A

µA

Input equals VDD

I/O pin pull-up and pull-down

resistor

kΩ

Table 20: DC Characteristics
