14 / 203 page  CC1110 CC1110 PRELIMINARY Datasheet (Rev. 1.01) SWRS033A Page 14 of 202 7.2 RF Receive Section TA=25°C, VDD=3.0V if nothing else stated. Measured on Chipcon’s CC1110 EM reference design. Parameter Min Typ Max Unit Condition/Note Differential input impedance TBD Ω Follow CC1110EM reference design –109 dBm 2-FSK, 1.2kbps, 5.2kHz deviation, 1% packet error rate, 20 bytes packet length, 58kHz digital channel filter bandwidth –99 dBm 2-FSK, 38.4kbps, 20kHz deviation, 1% packet error rate, 20 bytes packet length, 100kHz digital channel filter bandwidth -87 dBm 2-FSK, 250kbps, 127kHz deviation, 1% packet error rate, 20 bytes packet length, 540kHz digital channel filter bandwidth Receiver sensitivity 315/433/868/915MHz -86 dBm OOK, 250kbps OOK, 1% packet error rate, 20 bytes packet length, 540kHz digital channel filter bandwidth Saturation –15 dBm Digital channel filter bandwidth 58 812 kHz User programmable. The bandwidth limits are proportional to crystal frequency (given values assume a 26.0MHz crystal). Adjacent channel rejection, 868MHz 23 dB 2-FSK, 38.4kbps, 20kHz deviation, 1% packet error rate, 20 bytes packet length, 100kHz digital channel filter, 150kHz channel spacing Desired channel 3dB above the sensitivity limit. Alternate channel rejection, 868MHz 33 dB 2-FSK, 38.4kbps, 20kHz deviation, 1% packet error rate, 20 bytes packet length, 100kHz digital channel filter, 150kHz channel spacing Desired channel 3dB above the sensitivity limit. Image channel rejection, 868MHz 29 dB 2-FSK, 38.4kbps, 20kHz deviation, 1% packet error rate, 20 bytes packet length, 100kHz digital channel filter, 150kHz channel spacing, IF frequency 305kHz Desired channel 3dB above the sensitivity limit. Blocking at 1MHz offset, 868MHz 52 dB Desired channel 3dB above the sensitivity limit. Compliant to ETSI EN 300 220 class 2 receiver requirement. Blocking at 2MHz offset, 868MHz 54 dB Desired channel 3dB above the sensitivity limit. Compliant to ETSI EN 300 220 class 2 receiver requirement. Blocking at 5MHz offset, 868MHz 61 dB Desired channel 3dB above the sensitivity limit. Compliant to ETSI EN 300 220 class 2 receiver requirement. Blocking at 10MHz offset, 868MHz 64 dB Desired channel 3dB above the sensitivity limit. Compliant to ETSI EN 300 220 class 2 receiver requirement. Spurious emissions –57 –47 dBm dBm 25MHz – 1GHz Above 1GHz Table 6: RF Receive Section |
|
