CC1110

CC1110 PRELIMINARY Data Sheet (Rev. 1.01) SWRS033A

Page 1 of 202

True System-on-Chip with Low Power RF Transceiver and 8051 MCU

Applications

• 315/433/868 and 915 MHz ISM/SRD band

systems

• Low power telemetry

• Home and building automation

• AMR – Automatic Meter Reading

• Wireless alarm and security systems

• RKE – Two-way Remote Keyless Entry

• Consumer Electronics

• Wireless sensor networks

• Industrial monitoring and control

Product Description

The

CC1110 is a low-cost true System-on-Chip

(SoC) device designed for low-power and low-

voltage wireless communication applications.

The

CC1110

combines

the

excellent

performance of the state-of-the-art CC1100

RF transceiver with an industry-standard

enhanced 8051 MCU, 32 KB of in-system

programmable flash memory, 4 KB of RAM

and many other powerful features.

The

CC1110 is highly suited for systems where

very low power consumption is required. This

is ensured by several advanced low-power

operating modes.

The

CC1110 provides a tight integration

between the MCU core, software and the RF

transceiver,

making

this

System-on-Chip

solution easy to use as well as improving

performance.

CC1110 is supported by a powerful integrated

development environment (IDE). In-circuit

interactive debugging is supported for the

industry standard IAR C-SPY IDE via a simple

two-wire serial interface.

CC1110 is based on Chipcon’s SmartRF04®

technology platform in 0.18

µm CMOS.

The data sheet contains preliminary data, and supplementary data will be published at a later date. Chipcon

reserves the right to make changes at any time without notice in order to improve design and supply the best

possible product. The product at this point is not fully qualified.

Key Features

•

High performance and low power 8051

microcontroller core, typically with 8x the

performance per MHz of a standard 8051

•

High-performance RF transceiver core –

same as in the CC1100

•

Frequency bands: 300-348 MHz, 400-464

MHz and 800-928 MHz

•

Programmable data rate up to 500 kbps

•

32 KB in-system programmable flash

•

4 KB RAM

•

8-14 bits ADC with up to eight inputs

•

128-bit AES security coprocessor

•

Powerful DMA functionality

•

Two USARTs / SPI interfaces

•

16-bit timer + three 8-bit timers

•

Hardware debug support

•

21 general I/O pins

•

Wide supply voltage range (2.0V – 3.6V)

•

High sensitivity (–110 dBm at 1.2 kbps)

•

Programmable data rate up to 500 kbps
