background image
CC1110
CC1110 PRELIMINARY Datasheet (Rev. 1.01) SWRS033A
Page 188 of 202
0xDF1E: FSCAL1 – Frequency synthesizer calibration
Bit
Field Name
Reset
R/W
Description
7:6
-
00
R0
Reserved
5:0
FSCAL1[5:0]
0x02
R/W
Frequency synthesizer calibration result register.
Fast frequency hopping without calibration for each hop can be
done by calibrating upfront for each frequency and saving the
resulting FSCAL3, FSCAL2 and FSCAL1 register values. Between
each frequency hop, calibration can be replaced by writing the
FSCAL3, FSCAL2 and FSCAL1 register values corresponding to
the next RF frequency.
0xDF1F: FSCAL0 – Frequency synthesizer calibration
Bit
Field Name
Reset
R/W
Description
7
-
0
R0
Reserved
4:0
FSCAL0[6:0]
0x0D
R/W
Frequency synthesizer calibration control. The value to
use in this register is given by the SmartRF® Studio
software.
0xDF27: PA_TABLE7 – PA power setting 7
Bit
Field Name
Reset
R/W
Description
7:0
PA_TABLE7[7:0]
0x00
R/W
Power amplifier output power setting 7
Currently used PA output power is selected by
FREND0.PA_POWER[2:0]
0xDF28: PA_TABLE6 – PA power setting 6
Bit
Field Name
Reset
R/W
Description
7:0
PA_TABLE6[7:0]
0x00
R/W
Power amplifier output power setting 6
Currently used PA output power is selected by
FREND0.PA_POWER[2:0]
0xDF29: PA_TABLE5 – PA power setting 5
Bit
Field Name
Reset
R/W
Description
7:0
PA_TABLE5[7:0]
0x00
R/W
Power amplifier output power setting 5
Currently used PA output power is selected by
FREND0.PA_POWER[2:0]
0xDF2A: PA_TABLE4 – PA power setting 4
Bit
Field Name
Reset
R/W
Description
7:0
PA_TABLE4[7:0]
0x00
R/W
Power amplifier output power setting 4
Currently used PA output power is selected by
FREND0.PA_POWER[2:0]
