CC1110
CC1110 PRELIMINARY Datasheet (Rev. 1.01) SWRS033A
Page 134 of 202
13.11 Power On Reset
The
CC1110 includes a Power On Reset
(POR) in order to protect the memory
contents during supply voltage variations
and
provide correct initialization during
power-on.
When power is initially applied to the
CC1110 the Power On Reset (POR) will
hold the device in reset state until the
supply voltage reaches above the Power
On Reset voltage as defined in Table 4 on
page 12.
Figure 26 shows the POR operation with
the 1.8V (typical) regulated supply voltage
together with the active low reset signal
shown in the bottom of the figure.
The cause of the last reset can read from
the register bits SLEEP.RST.
0
UNREGULATED
1.8V REGULATED
POR RESET ASSERT FALLING VDD
POR RESET DEASSERT RISING VDD
VOLT
POR RESET
X
X
Figure 26 : Power On Reset Operation
