CC1110

CC1110 PRELIMINARY Datasheet (Rev. 1.01) SWRS033A

Page 103 of 202

T2CTL (0x9E) – Timer 2 Control

Bit

Name

Reset

R/W

Description

R/W0

Not used.

TEX

R/W0

Timer expired. This bit is set when the timer expires. Writing a 1 to this

bit has no effect

R/W

Reserved. Should always be written as 0

INT

R/W

Interrupt enable. Select interrupt generated on timer expiration

0 Interrupt disabled

1 Interrupt enabled

R/W

Reserved. Should always be written as 0

TIG

R/W

Tick generator mode.

0 Tick generator is running when

T2CT not equal to 00h. The tick

generator will always start running form its null state.

1 Tick generator is in free-running mode. If it is not already running it

will start from its null state when a ‘1’ is written to TIG.

1:0

TIP[1:0]

R/W

Tick period. Selects tick period based on prescaler multiplier value.

00 Tick period is T2PR * 64 clock cycles

01 Tick period is T2PR * 128 clock cycles

10 Tick period is T2PR * 256 clock cycles

11 Tick period is T2PR * 1024 clock cycles

T2CT (0x9C) – Timer 2 Count

Bit

Name

Reset

R/W

Description

7:0

CNT[7:0]

0x00

R/W

Timer count. Contents of 8-bit counter

T2PR (0x9D) – Timer 2 Prescaler

Bit

Name

Reset

R/W

Description

7:0

PR[7:0]

0x00

R/W

Timer prescaler multiplier. 0x00 is interpreted as 256
