Creating user's own keypad

Only the keys the user needs can be chosen, and the

keys to execute specified actions can be customized.

Resizing objects

The properties of the object size are added. You can

resize the objects suitable for your application.

Changing the keypad size

The size can be changed to suit the

user's needs.

Set variables as

minimum and

maximum values

You can easily restrict input

on the HMI or from the PLC.

■Custom keypads

■Resizing object

Specifying a page number

By assigning any number to the page, you can easily switch pages from the PLC.

The previously required subroutine is no longer needed for this operation. This feature is particularly helpful when

you use the CJ PLC in which pages are frequently specified by number.*1

To jump to the specified page, enter the number, which corresponds to the page number,

in the _HMI_CurrentPageIndex system-related variable.

Set the number you want to

assign to the page.

No.10

No.11

No.12

*1.This function is also supported in the NJ/NX/NY Series.

Customizing keypads and resizing objects

You can change the keypad size, choose only the keys you need, and customize the keys to execute specified actions.

Create your own keypad suitable for your applications.

The size of the Check Box, Slider, and Radio Button objects can also be changed. You can greatly improve the usability

of your machine by enlarging these objects in size.

Dynamically changing upper/lower limit value

The upper and lower limit values can be dynamically changed by setting variables as maximum and minimum

values of a Data Edit object. It is possible to restrict input according to the status of the machine.
