background image
Data Sheet
ADRF6755
Rev. B | Page 31 of 48
REGISTER MAP
REGISTER MAP SUMMARY
Table 8. Register Map Summary
Register Address (Hex)
Register Name
Type
Description
0x00
CR0
Read/write
Fractional Word 4
0x01
CR1
Read/write
Fractional Word 3
0x02
CR2
Read/write
Fractional Word 2
0x03
CR3
Read/write
Fractional Word 1
0x04
CR4
Read/write
Reserved
0x05
CR5
Read/write
5-bit reference dividers enable
0x06
CR6
Read/write
Integer Word 2
0x07
CR7
Read/write
Integer Word 1 and MUXOUT control
0x08
CR8
Read/write
Reserved
0x09
CR9
Read/write
Charge pump current setting
0x0A
CR10
Read/write
Reference frequency control
0x0B
CR11
Read/write
Reserved
0x0C
CR12
Read/write
PLL power-up
0x0D
CR13
Read/write
Lock Detector Control 2
0x0E
CR14
Read/write
TXDIS control
0x0F
CR15
Read/write
Reserved
0x10
CR16
Read/write
Reserved
0x11
CR17
Read/write
Reserved
0x12
CR18
Read/write
Reserved
0x13
CR19
Read/write
Reserved
0x14
CR20
Read/write
Reserved
0x15
CR21
Read/write
Reserved
0x16
CR22
Read/write
Reserved
0x17
CR23
Read/write
Lock Detector Control 1
0x18
CR24
Read/write
Autocalibration
0x19
CR25
Read/write
Autocalibration Timer
0x1A
CR26
Read/write
Reserved
0x1B
CR27
Read/write
LO monitor output and LO selection
0x1C
CR28
Read/write
LO selection
0x1D
CR29
Read/write
Modulator
0x1E
CR30
Read/write
Attenuator
0x1F
CR31
Read only
Reserved
0x20
CR32
Read only
Reserved
0x21
CR33
Read only
Revision code
