Cannon Straight PCB, Size 20

Military/High Reliability

Standard Density Straight PC Tail

C-14

www.ittcannon.com

Dimensions shown in inches (mm)

Specifications and dimensions subject to change

Shell Size

Layout

Through Hole

Dual Float Mount

DEM9PM*

DEMY9PM*

DAM15PM*

DAMY15PM*

DBM25PM*

DBMY25PM*

DCM37PM*

DCMY37PM*

DDM50PM*

DDMY50PM*

Dimensions

Plug

• For contact cavity arrangements, see pages C-44.

• For P.C. hole pattern, see pages C-45.

• For panel cutouts, see page C-49.

Note: For Residual Magnetism Level of 200 gamma, add NMBK52. Example

DEMA15PMNMBK52 contacts and shells with 50 microinches gold. For alternate PC

tail modifiers (see tabulation), replace 0L3 with M or Z. Example: DEM9PZNM

Shell

size ± 0,38 (.015) ± 0,13 (.005) ± 0,13 (.005) ± 0,13 (.005) ± 0,38 (.015) ± 0,25 (.010) ± 0,368 (.0145) ± 0,41 (.016) ± 0,317 (.0125) ± 0,25 (.010) ± 0,25

(.010)

30,81 (1.213)

16,92 (.666)

24,99 (8,36)

8,36 (.329)

12,55 (.494)

10,72 (.422)

6,693 (.2635)

1,206 (.0475)

0,76 (.030)

39,14 (1.541)

25,25 (.994)

33,32 (1.312)

8,36 (.329)

12,55 (.494)

10,72 (.422)

6,693 (.2635)

1,206 (.0475)

0,76 (.030)

53,04 (2.088)

38,96 (1.534)

47,04 (1.852)

8,36 (.329)

12,55 (.494)

10,82 (.426)

6.84 (.269)

1,52 (.060)

0,99 (.039)

69,32 (2.729)

55,42 (2.182)

63,50 (2.500)

8,36 (.329)

12,55 (.494)

10,82 (.426)

6.84 (.269)

1,52 (.060)

0,99 (.039)

66,93 (2.635)

52,81 (2.079)

61,11 (2.406)

11,07 (.436)

15,37 (.605)

10,82 (.426)

6.84 (.269)

1,52 (.060)

0,99 (.039)

10°

Ø 3,05

(.120)

Ø Y

2,84

(.112)

5,69

(.224)

Sizes E, A, B, C

Size D

PC Tail Modifiers

ØY

4.01 ± 0,69

0,76 ± 0,08

(.158 ± .027)

(.030 ± .003)

7,62 ± 0,5

0,76 ± 0,08

(.300 ± .020)

(.030 ± .003)

0L3

4,82 ± 1,5

0,60 ± 0,08

(.190 ± .020)

(.023 ± .003)

0L3 for HE501 connectors and ESA equivalents
