Dimensions shown in inches (mm)

Specifications and dimensions subject to change

C

Cannon 90° PCB, Size 20

Military/High Reliability

90° Standard Density PC Tail

Shell Size

Layout

Through Hole

Through Hole

with bracket

without bracket

DE

9

DEMM9PL

DEMM9P

DA

15

DAMM15PL

DEMM15P

DB

25

DBMM25PL

DEMM25P

DC

37

DCMM37PL

DEMM37P

DD

50

DDMM50PL

DEMM50P

Plug

Note: For Residual Magnetism Level of 200 gamma, add NMBK52.

Example DEMA9PLNMBK52 contacts and shells have 50 microinches gold.

Shown with bracket, for version without bracket, use termination modifier "P".

Shell

A

B

C

D

E

F

W

W

K

K

L

size ± 0,38 (.015) ± 0,13 (.005) ± 0,13 (.005) ± 0,13 (.005) ± 0,38 (.015) ± 0,25 (.010) ± 0,368 (.0145) ± 0,41 (.016) ± 0,317 (.0125) ± 0,25 (.010) ± 0,25 (.010)

DE

30,81 (1.213)

16,92 (.666)

24,99 (8,36)

8,36 (.329)

12,55 (.494)

10,72 (.422)

6,693 (.2635)

-

0,76 (.030)

12,30 (.484)

8,64 (.340)

DA

39,14 (1.541)

25,25 (.994)

33,32 (1.312)

8,36 (.329)

12,55 (.494)

10,72 (.422)

6,693 (.2635)

-

0,76 (.030)

12,30 (.484)

8,64 (.340)

DB

53,04 (2.088)

38,96 (1.534)

47,04 (1.852)

8,36 (.329)

12,55 (.494)

10,82 (.426)

-

6.84 (.269)

0,76 (.030)

12,30 (.484)

8,64 (.340)

DC

69,32 (2.729)

55,42 (2.182)

63,50 (2.500)

8,36 (.329)

12,55 (.494)

10,82 (.426)

-

6.84 (.269)

0,76 (.030)

12,30 (.484)

8,64 (.340)

DD

66,93 (2.635)

52,81 (2.079)

61,11 (2.406)

11,07 (.436)

15,37 (.605)

10,82 (.426)

-

6.84 (.269)

0,76 (.030)

15,09 (.594)

10,04 (.395)

Engaging Face

DD Configuration

A

C

B

D

E

10

°

Ø 0,76 (.030)

M

N

Ø 3,05

(.120)

2,84

(.112)

7,18

± 0,25

(.283

± .010)

5,68

(.224)

L

4,01

± 0,69

(.158

± .027)

2,84

(.112)

F

W

7,18

± 0,25

(.283

± .010)

4,01

± 0,69

(.158

± .027)

Size D

Size E, A, B, C
