Environmental D

D*D

The Cannon D*D Environmental Series is designed

to meet the demand for subminiature rectangular

plugs with superior vibration and moisture resist-

ance characteristics for aircraft, missile, and ground

support equipment applications.

Featuring a rugged aluminum shell and peripheral

seal, the D*D connector meets all applicable re-

quirements of MIL-C-24308. Available in both sol-

der and crimp versions, all assemblies are provided

with nylon potting cups and dust caps.

Solder type contacts are non-removable and are

factory-installed. Crimp type connectors utilize the

field-proven LITTLE CAESAR® rear insertion, rear-re-

lease retention system.

PLEASE NOTE: The D*D Series is not intermate-

able with other D Subminiature connectors.

Performance and Material Specifications

Shell

Aluminum, cadmium plated with yellow chromate supplementary coating.

Contacts

Solder pot: Copper alloy, gold plated .00002 (.0005) over nickel .00004 (.0010)

Crimp type: Copper alloy, gold plated .00002 (.0005) over nickel .00004 (.0010)

Contact Termination

Solder pot accommodating up to #20 AWG stranded wire. Crimp type accommodat-

ing #20, #22, and #24 AWG stranded wire.

Socket Type

Closed entry

Float Mounting Rivets & Washers

Stainless Steel. Passivated per DQ-P-35

Test Data

Specifications

Voltage Rating

All voltage figures are AC (rms), 60 Hz measured at approximately 25.0°C 50% RH.

Insulation Resistance

Greater than 5,000 megohms, determined in accordance with MIL-STD-202A, Method 302

(per MIL-C-24308)

Contact Voltage Drop

2.67 millivolts, maximum, per amp

Contact Separation Force 1 to 8 ounces when tested in accordance with MIL-C-24308

Air Leakage

When properly wired and potted, 1 cubic inch of air per hour max. when subjected to 30 PSI

pressure differential in accordance with MIL-C-50150, Paragraph 4.5.3.1

Vibration

Exceeds test requirements of MIL-STD-202A, Method 204, Condition D

(per MIL-C-24308)

Corrosion Resistance

Exceeds requirements of 50 hour exposure to salt spray in accordance with MIL-STD-202A,

(per MIL-C-24308)

Method 101A, Condition B

Moisture Resistance

Exceeds requirements of MIL-STD-202A, Method 106

(per MIL-C-24308)

Shock

Exceeds requirements of MIL-STD-202A, Method 213, Condition G

Environmental Seal

Effective from full engagement to 1/16 short of full engagement

Contact Retention Force

(Crimp type) 8 pounds (35.6 newtons) minimum for first cycle; 5 pounds (22.2 newtons)

minimum after tenth cycle

Standard Layout Plugs

Measured from contact-to-contact, and contact-to-shell in unmated condition

ALTITUDE (FEET)

Sea

Level

20,000

50,000

70,000

Average

Flashover

1700

1000

650

500

Test

1250

750

475

375
