103 / 150 page  PCI Express Extended Configuration Space 91 November 2005 SCPS097B 5.5 Uncorrectable Error Severity Register The uncorrectable error severity register controls the reporting of individual errors as ERR_FATAL or ERR_NONFATAL. When a bit is set, the corresponding error condition is identified as fatal. When a bit is cleared, the corresponding error condition is identified as nonfatal. See Table 5−4 for a complete description of the register contents. PCI Express extended register offset: 10Ch Register type: Read-only, Read/Write Default value: 0006 2011h BIT NUMBER 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 RESET STATE 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1 0 BIT NUMBER 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0 RESET STATE 0 0 1 0 0 0 0 0 0 0 0 1 0 0 0 1 Table 5−4. Uncorrectable Error Severity Register Description BIT FIELD NAME ACCESS DESCRIPTION 31:21 RSVD R Reserved. Returns 000 0000 0000b when read. 20† UR_ERROR_SEVR RW Unsupported request error severity 0 = Error condition is signaled using ERR_NONFATAL (default) 1 = Error condition is signaled using ERR_FATAL 19† ECRC_ERROR_SEVR RW Extended CRC error severity 0 = Error condition is signaled using ERR_NONFATAL (default) 1 = Error condition is signaled using ERR_FATAL 18† MAL_TLP_SEVR RW Malformed TLP severity 0 = Error condition is signaled using ERR_NONFATAL 1 = Error condition is signaled using ERR_FATAL (default) 17† RX_OVERFLOW_SEVR RW Receiver overflow severity 0 = Error condition is signaled using ERR_NONFATAL 1 = Error condition is signaled using ERR_FATAL (default) 16† UNXP_CPL_SEVR RW Unexpected completion severity 0 = Error condition is signaled using ERR_NONFATAL (default) 1 = Error condition is signaled using ERR_FATAL 15† CPL_ABORT_SEVR RW Completer abort severity 0 = Error condition is signaled using ERR_NONFATAL (default) 1 = Error condition is signaled using ERR_FATAL 14† CPL_TIMEOUT_SEVR RW Completion time-out severity 0 = Error condition is signaled using ERR_NONFATAL (default) 1 = Error condition is signaled using ERR_FATAL 13† FC_ERROR_SEVR RW Flow control error severity 0 = Error condition is signaled using ERR_NONFATAL 1 = Error condition is signaled using ERR_FATAL (default) 12† PSN_TLP_SEVR RW Poisoned TLP severity 0 = Error condition is signaled using ERR_NONFATAL (default) 1 = Error condition is signaled using ERR_FATAL 11:5 RSVD R Reserved. Returns 000 0000b when read. 4† DLL_ERROR_SEVR RW Data link protocol error severity 0 = Error condition is signaled using ERR_NONFATAL 1 = Error condition is signaled using ERR_FATAL (default) 3:1 RSVD R Reserved. Return 000b when read. 0 RSVD R Reserved. Returns 1b when read. † These bits are reset by a PCI Express reset (PERST), a GRST, or the internally-generated power-on reset. |
|
