Classic PCI Configuration Space

November 2005

SCPS097B

4.16 I/O Limit Register

This read/write register specifies the upper limit of the I/O addresses that the bridge forwards downstream.

See Table 4−7 for a complete description of the register contents.

PCI register offset:

1Dh

Read-only, Read/Write

Default value:

01h

BIT NUMBER

RESET STATE

Table 4−7. I/O Limit Register Description

BIT

FIELD NAME

ACCESS

DESCRIPTION

7:4

IOLIMIT

I/O limit. Defines the top address of the I/O address range that determines when to forward I/O

transactions from one interface to the other. These bits correspond to address bits [15:12] in the

I/O address. The lower 12 bits are assumed to be FFFh. The 16 bits corresponding to address bits

[31:16] of the I/O address are defined in the I/O limit upper 16 bits register (offset 32h, see

Section 4.25).

3:0

IOTYPE

I/O type. This field is read-only 1h indicating that the bridge supports 32-bit I/O addressing.
