Classic PCI Configuration Space

November 2005

SCPS097B

4.33 Power Management Control/Status Register

This register determines and changes the current power state of the bridge. No internal reset is generated

when transitioning from the D3hot state to the D0 state. See Table 4−19 for a complete description of the

PCI register offset:

54h

Read-only, Read/Write

Default value:

0000h

BIT NUMBER

RESET STATE

Table 4−19. Power Management Control/Status Register Description

BIT

FIELD NAME

ACCESS

DESCRIPTION

PME_STAT

PME status. This bit is read-only and returns 0b when read.

14:13

DATA_SCALE

Data scale. This 2-bit field returns 00b when read since the bridge does not use the data

12:9

DATA_SEL

Data select. This 4-bit field returns 0h when read since the bridge does not use the data

PME_EN

PME enable. This bit has no function and acts as scratchpad space. The default value for this

bit is 0b.

7:4

RSVD

Reserved. Returns 0h when read.

NO_SOFT_RESET

No soft reset. If bit 26 (PCI_PM_VERSION_CTRL) in the general control register (offset D4h,

see Section 4.65) is 0b, then this bit returns 0b for compatibility with version 1.1 of the PCI

Power Management Specification. If PCI_PM_VERSION_CTRL is 1b, then this bit returns 1b

indicating that no internal reset is generated and the device retains its configuration context

when transitioning from the D3hot state to the D0 state.

RSVD

Reserved. Returns 0b when read.

1:0

PWR_STATE

Power state. This 2-bit field determines the current power state of the function and sets the

function into a new power state. This field is encoded as follows:

00 = D0 (default)

01 = D1

10 = D2

11 = D3hot

4.34 Power Management Bridge Support Extension Register

This read-only register indicates to host software what the state of the secondary bus will be when the bridge

is placed in D3. See Table 4−20 for a complete description of the register contents.

PCI register offset:

56h

Read-only

Default value:

40h

BIT NUMBER

RESET STATE

Table 4−20. Power Management Bridge Support Extension Register Description

BIT

FIELD NAME

ACCESS

DESCRIPTION

BPCC

Bus power/clock control enable. This bit indicates to the host software if the bus secondary clocks

are stopped when the bridge is placed in D3. The state of the BPCC bit is controlled by bit 11

(BPCC_E) in the general control register (offset D4h, see Section 4.65).

0 = The secondary bus clocks are not stopped in D3

1 = The secondary bus clocks are stopped in D3

BSTATE

B2/B3 support. This bit is read-only 1b indicating that the bus state in D3 is B2.

5:0

RSVD

Reserved. Returns 00 0000b when read.
