On-chip peripherals

ST7LITEUS2, ST7LITEUS5

82/136

10.3.5

Interrupts

None.

10.3.6

Control/Status register (ADCCSR)

Reset value: 0000 0000 (00h)

Note:

A write to the ADCCSR register (with ADON set) aborts the current conversion, resets the

EOC bit and starts a new conversion.

EOC

SPEED

ADON

CH2

CH1

CH0

Read/Write (Except bit 7 read only)

Bit 7 EOC End of Conversion

This bit is set by hardware. It is cleared by software reading the ADCDRH register.

0: Conversion is not complete

1: Conversion complete

Bit 6 SPEED ADC clock selection

This bit is set and cleared by software. It is used together with the SLOW bit to

configure the ADC clock speed. Refer to the table in the SLOW bit description.

Bit 5 ADON A/D Converter on

This bit is set and cleared by software.

0: A/D converter is switched off

1: A/D converter is switched on

Bits 4:3 Reserved. Must be kept cleared.

Bits 2:0 CH[2:0] Channel Selection

These bits are set and cleared by software. They select the analog input to convert.

Table 32.

Channel selection

Channel pin

CH2

CH1

CH0

AIN0

AIN1

AIN2

AIN3

AIN4
