Data Sheet

ADP1046A

Rev. 0 | Page 81 of 88

Table 138. Register 0x94—EEPROM_DATA_09

Bits

Bit Name

Type

Description

Variable

EEPROM_DATA_09

Block read/

write

Block read or write from the EEPROM main block, Page 9. To write to this page, the

EEPROM must first be unlocked. This page is available to the user for storing data.

Table 139. Register 0x95—EEPROM_DATA_10

Bits

Bit Name

Type

Description

Variable

EEPROM_DATA_10

Block read/

write

Block read or write from the EEPROM main block, Page 10. To write to this page, the

EEPROM must first be unlocked. This page is available to the user for storing data.

Table 140. Register 0x96—EEPROM_DATA_11

Bits

Bit Name

Type

Description

Variable

EEPROM_DATA_11

Block read/

write

Block read or write from the EEPROM main block, Page 11. To write to this page, the

EEPROM must first be unlocked. This page is available to the user for storing data.

Table 141. Register 0x97—EEPROM_DATA_12

Bits

Bit Name

Type

Description

Variable

EEPROM_DATA_12

Block read/

write

Block read or write from the EEPROM main block, Page 12. To write to this page, the

EEPROM must first be unlocked. This page is available to the user for storing data.

Table 142. Register 0x98—EEPROM_DATA_13

Bits

Bit Name

Type

Description

Variable

EEPROM_DATA_13

Block read/

write

Block read or write from the EEPROM main block, Page 13. To write to this page, the

EEPROM must first be unlocked. This page is available to the user for storing data.

Table 143. Register 0x99—EEPROM_DATA_14

Bits

Bit Name

Type

Description

Variable

EEPROM_DATA_14

Block read/

write

Block read or write from the EEPROM main block, Page 14. To write to this page, the

EEPROM must first be unlocked. This page is available to the user for storing data.

Table 144. Register 0x9A—EEPROM_DATA_15

Bits

Bit Name

Type

Description

Variable

EEPROM_DATA_15

Block read/

write

Block read or write from the EEPROM main block, Page 15. To write to this page, the

EEPROM must first be unlocked. This page is available to the user for storing data.
