MPC8544E PowerQUICC III Integrated Processor Hardware Specifications, Rev. 5

Freescale Semiconductor

Package Description

AVDD_SRDS

W28

Power for

SRDSPLL

(1.0 V)

—19

AVDD_SRDS2

AG1

Power for

SRDSPLL

(1.0 V)

—19

SENSEVDD

W11

VDD

SENSEVSS

W10

—

Analog Signals

MVREF

A28

Reference

voltage signal

for DDR

MVREF

—

SD1_IMP_CAL_RX

M26

—

200

Ω to GND

—

SD1_IMP_CAL_TX

AE28

—

100

Ω to GND

—

SD1_PLL_TPA

V26

—

AVDD_SRDS

ANALOG

SD2_IMP_CAL_RX

AH3

200

Ω to GND

—

SD2_IMP_CAL_TX

100

Ω to GND

—

SD2_PLL_TPA

AH1

AVDD_SRDS2

ANALOG

No Connect Pins

C19, D7, D10, K13, L6, K9, B6, F12, J7, M19,

M25, N19, N24, P19, R19, AB19, T12, W3,

M12, W5, P12, T19, W1, W7, L13, U19, W4, V8,

V9, V10, V11, V12, V13, V14, V15, V16, V17,

V18, V19, W2, W6, W8, T11, U11, W12, W13,

W14, W15, W16, W17, W18, W19, W27, V25,

Y17, Y18, Y19, AA18, AA19, AB20, AB21,

AB22, AB23, J9

——

—

Notes:

1.All multiplexed signals are listed only once and do not re-occur. For example, LCS5/DMA_REQ2 is listed only once in the

Local Bus Controller Interface section, and is not mentioned in the DMA section even though the pin also functions as

DMA_REQ2.

2.Recommend a weak pull-up resistor (2–10 K

Ω) be placed on this pin to OV

DD.

3.This pin must always be pulled high.

4.This pin is a reset configuration pin. It has a weak internal pull-up P-FET which is enabled only when the processor is in the

reset state. This pull-up is designed such that it can be overpowered by an external 4.7-k

Ω pull-down resistor. However, if

the signal is intended to be high after reset, and if there is any device on the net which might pull down the value of the net

at reset, then a pull-up or active driver is needed. TSEC3_TXD[3] (cfg_srds_sgmii_refclk) is an exception, because the

default value of this configuration signal is low (0). Thus, no external pull-down resistor is needed for selecting the default

configuration value.

5. Treat these pins as no connects (NC) unless using debug address functionality.

Table 62. MPC8544E Pinout Listing (continued)

Signal

Package Pin Number

Pin Type

Power

Supply

Notes
