ELECTRICAL SPECIFICATIONS

Release 1.3 - January 29, 2002

41/87

This is preliminary information on a new product now in development or undergoing evaluation. Details are subject to change without notice.

4.5.4. PCI INTERFACE

Table 4-9 lists the AC characteristics of the PCI in-

terface.

Table 4-9. PCI Bus AC Timing

Name

Parameter

Min

Max

Unit

PCI_CLKI to AD[31:0] valid

9.3

PCI_CLKI to FRAME valid

7.14

PCI_CLKI to CBE[3:0] valid

7.94

PCI_CLKI to PAR valid

9.34

PCI_CLKI to TRDY valid

8.8

PCI_CLKI to IRDY valid

7.74

PCI_CLKI to STOP valid

9.4

PCI_CLKI to DEVSEL valid

8.5

PCI_CLKI to PCI_GNT valid

7.14

AD[31:0] bus setup to PCI_CLKI

5.42

FRAME setup to PCI_CLKI

5.03

CBE[3:0] setup to PCI_CLKI

6.37

IRDY setup to PCI_CLKI

4.52

PCI_REQ[2:0] setup to PCI_CLKI

5.29

AD[31:0] bus hold from PCI_CLKI

-0.91

FRAME hold from PCI_CLKI

-1.8

CBE[3:0] hold to PCI_CLKI

-2.9

IRDY hold to PCI_CLKI

-1.6

PCI_REQ[2:0] hold from PCI_CLKI

-3.49
