IP101G

Data Sheet

40/65

January 14, 2014

IP101G-DS-R01

MII page16 Register26~27

page

MII

ROM R/W

Description

Default

26[14:12]

R/W RXDV_DRIVE

RXDV PAD Driving Current is defined as same as RXC.

3’b001

26[11:9]

R/W RXD3_DRIVE

RXD3 PAD Driving Current is defined as same as RXC.

3’b001

26[8:6]

R/W RXD2_DRIVE

RXD2 PAD Driving Current is defined as same as RXC.

3’b001

26[5:3]

R/W RXD1_DRIVE

RXD1 PAD Driving Current is defined as same as RXC.

3’b001

26[2:0]

R/W RXD0_DRIVE

RXD0 PAD Driving Current is defined as same as RXC.

3’b001

27[15]

RO Reserved

27[14:12]

R/W MDIO_DRIVE

MDIO PAD Driving Current is defined as same as RXC.

3’b000

27[11:9]

R/W COL_DRIVE

COL PAD Driving Current is defined as same as RXC.

3’b000

27[8:6]

R/W CRS_DRIVE

CRS PAD Driving Current is defined as same as RXC.

3’b000

27[5:3]

R/W Reserved

3’b010

27[2:0]

R/W TXC_DRIVE

TXC PAD Driving Current is defined as same as RXC.

3’b010

The other Registers are reserved registers. User is inhibited to access to these registers. It may

introduce abnormal function to write these registers.
