B7A

I/O Combination Models

Screw terminal model

(16 input and 16 output points)

Screw terminal model

(16 input and 16 output points)

B7AM

Screw terminal model

(8 input and 8 output points)

Screw terminal model

(8 input and 8 output points)

Input

Output

Input

Output

Input

Output

Input

Output

B7AM

Input (Transmission)

Output (Reception)

B7A

Screw terminal model (16 points)

Modular model (16 points)

PLC connector model (16 points)

Hybrid IC model (16 points)

PLC connector model (16 points)

Hybrid IC model (16 points)

Screw terminal model (16 points)

PLC connector model (32 points)

B7AS

Screw terminal model with

relay outputs (16 points)

Note:

Only normal I/O delay

time (typically 19.2 ms)

is available.

Note:

Two B7AM

Terminals

are

required for

32 inputs.

Note:

Two B7AM

Terminals

are

required for

32 outputs.

I/O combination screw terminal model

(16 inputs, 16 outputs)

Output

Input

B7AM

Set the I/O delay time setting switch to

the setting of B7A Terminals used in

combination.
