28 / 121 page

B7A/B7AS

B7AS-T6B1/-T6B6

(Input, Active Low)

Note:

1. The wire colors have been changed in accordance with the revision of the Japanese Industrial Standards for photoelectric

sensors and proximity sensors. The colors in parentheses refer to the old colors.

2. Do not short-circuit the SIG terminal with the positive power supply terminal, negative power supply terminal, or a B

terminal, otherwise the internal elements of the B7A will be damaged and no transmission will be possible.

SIG

–

12 to

24 VDC

Transmission

Three-

wire

sensor

Two-

wire

sensor

Brown (red)

Blue (black)

Black (white)

Blue (black)

Brown (white)

Contact

switch

Black

(white)

SIG

–

IN1

IN3

IN5

IN7

IN9

IN11

A11

IN13

A13

IN15

A15

–

IN0

IN2

IN4

IN6

IN8

IN10

A10

IN12

A12

IN14

A14

12 to 24 VDC

Power

supply

Power

supply

–

Brown

(red)

Blue

(black)

Blue

(black)

Brown

(white)

Photoelectric sensor

Three-wire proximity sensor with

built-in amplifier (with NPN output)

Two-wire DC

proximity sensor

Limit switch
