B7A

Indicator Operation

16-point Terminal Models

Indicator

Function

POWER

(Input Terminal)

Lit when power is supplied and the

Terminal is operating.

Not lit when power is not supplied.

POWER/ERR

(Output Terminal)

Lit when power is supplied and the

Terminal is operating without error.

Lit during transmission errors.

Not lit when power is not supplied.

Note:

G: Green indicator lit; R: Red indicator lit; N: Not lit

32-point Terminal Models

Indicator

Function

POWER

(Input Terminal)

Lit when power is supplied and the

Terminal is operating.

Not lit when power is not supplied.

ERR1/ERR2

(Output Terminal)

Not lit when power is supplied and

the Terminal is operating without

error.

Lit during transmission errors.

Not lit when power is not supplied.

Note:

G: Green indicator lit; R: Red indicator lit; N: Not lit

Recommended Solderless Terminals

Wire

JIS specifications

0.75 mm2 (AWG#18)

RAV 1.25 to 3.5 (vinyl-insulated round

wire) or RAP 1 25 to 3 5

1.25 mm2 (AWG#16)

wire) or RAP 1.25 to 3.5

(nylon-insulated round wire)

Setting of Output Selector (Output Unit Only)

16-point Terminal Models

OUTPUT SELECTOR

OUT15

ERR

Switch

OUT15

ERR

Set the 16th output to

OUT15.

Set the 16th output to ERR (the

ERR output is ON only when

there is a transmission error).

32-point Terminal Models

OUTPUT SELECTOR

OUT15 ERR1 OUT31 ERR2

Selector 1 Selector 2

Switch 1

Switch 2

OUT15

ERR1

OUT31

ERR2

Set the 16th output to OUT15.

Set the 16th output to ERR (the

ERR output is ON only when

there is a transmission error).

Set the 32nd output to OUT31.

Set the 32nd output to ERR

(the ERR output is ON only

when there is a transmission

error).
