57
Link Terminals with 8 Inputs and 8 Outputs
B7AM-8
j
Transmission Units Transmitting Input
and Output Signals
Transmit eight input signals and eight output
signals over three wires (or four wires if only one
terminal has power supply).
Transistor and relay inputs can be connected to the
input terminals.
Compact and space-saving.
Ordering Information
Model Number Legend
B7AM - 8
34
1. Classification
M:I/O combination model
2. Number of I/O
8: Eight input points and eight output points
3. Input/Output Configuration
B: NPN input and 100-mA NPN open collector output per point
F: PNP input and 100-mA PNP open collector output per point
4. Error Processing
1: HOLD
3: LOAD OFF
5. I/O Delay Time (Typical)
1: 19.2 ms (Screw terminals)
6: 3 ms (Screw terminals)
1
2
5
Product List
Refer to page 114 for details.
I/O Combinations
Refer to pages 1 to 5 for details.
